Amphenol RF 112352
The picture is for reference only, please refer to the product specification
- 112352
- Amphenol RF
- CONN BNC PLUG STR 50 OHM CRIMP
- Coaxial Connectors (RF)
- 112352 Datasheet
- -
- -
-
Lead free / RoHS Compliant - 2439
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is 112352
Amphenol RF Part Number 112352（Coaxial Connectors (RF)）, developed and manufactured by Amphenol RF, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
112352 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
112352 Specifications
- Part Number112352
- CategoryCoaxial Connectors (RF)
- ManufacturerAmphenol RF
- DescriptionCONN BNC PLUG STR 50 OHM CRIMP
- Package-
- Series-
- Mounting TypeFree Hanging (In-Line)
- Frequency - Max4GHz
- Impedance50 Ohm
- Ingress ProtectionWeatherproof
- Connector TypePlug, Male Pin
- Contact TerminationCrimp
- Connector StyleBNC
- Fastening TypeBayonet Lock
- Housing ColorSilver
- Shield TerminationClamp
- Number of Ports1
- Cable GroupRG-58, 58A, 58B, 58C, 141, 303, LMR-195, Belden B7806A, 9907
Application of 112352
112352 Datasheet
112352 Datasheet , Free Hanging (In-Line),4GHz,50 Ohm,Weatherproof,Plug, Male Pin,Crimp,BNC,Bayonet Lock,Silver,Clamp,1,RG-58, 58A, 58B, 58C, 141, 303, LMR-195, Belden B7806A, 9907
112352 Classification
Coaxial Connectors (RF)
FAQ about Coaxial Connectors (RF)
-
1. What is a coaxial connector?
Device for connecting coaxial cables
A coaxial connector is a device used to connect coaxial cables or other electronic devices, primarily used in radio frequency (RF) and microwave communications systems. It effectively reduces signal loss and provides good shielding to prevent electromagnetic interference (EMI).
Basic structure and working principle
The basic structure of a coaxial connector includes an inner conductor, an insulator, an outer conductor and a shield. The inner conductor is usually needle-shaped or hole-shaped, the insulator isolates the inner and outer conductors, and the outer conductor and shielding layer provide electromagnetic shielding to prevent signal interference. -
2. What is the difference between RF connectors and coaxial connectors?
Structure and performance indicators
There are significant differences between RF connectors and coaxial connectors in structure, application scenarios and performance indicators.
Structural differences
Coaxial connector: Coaxial connector consists of inner conductor, insulation layer, outer conductor and sheath. The inner conductor is used to connect the signal line, and the outer conductor not only serves as the ground wire of the signal line, but also acts as a shield against electromagnetic fields to prevent signal interference.
RF connector: RF connector usually refers to RF coaxial connector, which is similar in structure to coaxial connector, but RF connector focuses more on the transmission of high-frequency signals, so it has higher requirements in material selection and manufacturing process. .
Differences in performance metrics
Characteristic impedance: Characteristic impedance is an important indicator of RF coaxial connectors, which determines the impedance type of the cable connected to it. The characteristic impedance is determined by the inner diameter of the outer conductor, the outer diameter of the inner conductor, and the dielectric constant of the medium between the inner and outer conductors.
Voltage standing wave ratio: The voltage standing wave ratio reflects the matching level of the connector and is an important parameter to measure the performance of the connector.
To sum up, coaxial connector focuses more on general signal transmission, while RF connector focuses on optimized transmission of high-frequency signals. Both have different emphasis on structure, application scenarios and performance indicators.
-
3. What is also called an RF connector?
RF coaxial connector
RF connector, also called radio frequency coaxial connector, is a type of radio frequency connector. RF connectors are mainly used for the transmission and connection of radio frequency signals and are widely used in wireless communications, radio, television, radar and other fields.
historical background
The earliest RF connector-UHF connector was born in 1930. During World War II, due to war needs, the development of radio, radar and microwave communications promoted the innovation of RF connectors, and series connectors such as BNC, TNC, and N appeared34. After 1958, SMA, SMB, SMC, etc. were miniaturized Products came out one after another. In 1964, the United States formulated the "General Specification for Radio Frequency Coaxial Connectors", which promoted the standardization, serialization and generalization of RF connectors.
