What is 824551650

Würth Elektronik Part Number 824551650（TVS - Diodes）, developed and manufactured by Würth Elektronik, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

824551650 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

824551650 Specifications

  • Part Number824551650
  • CategoryTVS - Diodes
  • ManufacturerWürth Elektronik
  • DescriptionTVS DIODE 6.5VWM 11.2VC DO214AB
  • PackageDO-214AB, SMC
  • SeriesWE-TVSP
  • TypeZener
  • Operating Temperature-65°C ~ 150°C (TJ)
  • Mounting TypeSurface Mount
  • Package / CaseDO-214AB, SMC
  • Supplier Device PackageDO-214AB
  • ApplicationsGeneral Purpose
  • Voltage - Reverse Standoff (Typ)6.5V (Max)
  • Voltage - Breakdown (Min)7.6V (Typ)
  • Voltage - Clamping (Max) @ Ipp11.2V
  • Current - Peak Pulse (10/1000µs)267.9A
  • Power - Peak Pulse3000W (3kW)
  • Power Line ProtectionNo
  • Bidirectional Channels1

Application of 824551650

TVS - Diodes play a vital role in the design of electronic products, and its application fields are very wide. In the field of consumer electronics, such as smartphones, tablets, televisions, etc., TVS diodes are used to protect internal integrated circuits from electrostatic discharge and power fluctuations. In the field of industrial automation, they are used to protect critical equipment such as motor drives and PLC (programmable logic controllers) to ensure the stable operation of production lines. In addition, TVS diodes are also essential components in automotive electronic systems, which can protect on-board electronic systems from transient voltages caused by engine ignition, load mutations, etc. In the field of communication and data transmission, TVS diodes are also used to protect signal transmission lines to ensure the integrity and reliability of data transmission. In general, TVS diodes, with their excellent transient voltage protection capabilities, play an irreplaceable role in ensuring the safe and stable operation of electronic equipment.

824551650 Datasheet

824551650 Datasheet , DO-214AB, SMC,WE-TVSP,Zener,-65°C ~ 150°C (TJ),Surface Mount,DO-214AB, SMC,DO-214AB,General Purpose,6.5V (Max),7.6V (Typ),11.2V,267.9A,3000W (3kW),No,1

824551650 Classification

TVS - Diodes

TVS - Diodes are electronic components designed to protect circuits from transient overvoltage damage. They protect other sensitive components in the circuit from damage by quickly switching on and directing excess transient voltage to ground or power supply. TVS diodes are typically constructed of PN junction or metal oxide semiconductor structures with extremely fast response times and low clamping voltage characteristics. Its design principle is based on the avalanche breakdown effect, that is, when a specific voltage threshold is reached, the diode will rapidly change from a high resistance state to a low resistance state, limiting the transient voltage to a safe level. TVS diodes are used in a wide variety of electronic devices, especially those that need to protect critical circuits from lightning strikes, electrostatic discharges, or other transient voltage events.
