FQP6N90C

ON Semiconductor FQP6N90C

The picture is for reference only, please refer to the product specification

  • FQP6N90C
  • ON Semiconductor
  • MOSFET N-CH 900V 6A TO220-3
  • Transistors - FETs, MOSFETs - Single
  • FQP6N90C Datasheet
  • TO-220-3
  • Tube
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 3580
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is FQP6N90C

ON Semiconductor Part Number FQP6N90C（Transistors - FETs, MOSFETs - Single）, developed and manufactured by ON Semiconductor, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

FQP6N90C is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

FQP6N90C Specifications

  • Part NumberFQP6N90C
  • CategoryTransistors - FETs, MOSFETs - Single
  • ManufacturerON Semiconductor
  • DescriptionMOSFET N-CH 900V 6A TO220-3
  • PackageTube
  • SeriesQFET®
  • Operating Temperature-55°C ~ 150°C (TJ)
  • Mounting TypeThrough Hole
  • Package / CaseTO-220-3
  • Supplier Device PackageTO-220-3
  • TechnologyMOSFET (Metal Oxide)
  • Power Dissipation (Max)167W (Tc)
  • FET TypeN-Channel
  • FET Feature-
  • Drain to Source Voltage (Vdss)900 V
  • Current - Continuous Drain (Id) @ 25°C6A (Tc)
  • Rds On (Max) @ Id, Vgs2.3Ohm @ 3A, 10V
  • Vgs(th) (Max) @ Id5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs40 nC @ 10 V
  • Input Capacitance (Ciss) (Max) @ Vds1770 pF @ 25 V
  • Vgs (Max)±30V
  • Drive Voltage (Max Rds On, Min Rds On)10V

Application of FQP6N90C

FET and MOSFET-single (FETs, MOSFETs-Single) application field is extremely wide, almost covers the core part of all electronic devices. In the field of consumer electronics, from smartphones, tablets to wearable devices, FETs and MOSFETs are key components for signal processing and power management, ensuring the normal operation of devices and efficient energy consumption. In industrial control systems, they are widely used in the fields of motor drive, automated production lines and process control, improving production efficiency and system stability. In addition, in automotive electronics, medical equipment, aerospace and other high-tech fields, FET and MOSFET also play an irreplaceable role. In automotive electronics, for example, they are used in engine management systems, safety systems, and entertainment systems. In medical equipment, it is used for key links such as signal amplification and power control of precision instruments.

FQP6N90C Datasheet

FQP6N90C Datasheet , Tube,QFET®,-55°C ~ 150°C (TJ),Through Hole,TO-220-3,TO-220-3,MOSFET (Metal Oxide),167W (Tc),N-Channel,900 V,6A (Tc),2.3Ohm @ 3A, 10V,5V @ 250µA,40 nC @ 10 V,1770 pF @ 25 V,±30V,10V

FQP6N90C Classification

Transistors - FETs, MOSFETs - Single

FET (field effect transistor) is an electronic device that controls the flow of current in a semiconductor based on the electric field effect. It is mainly composed of three ends: Gate, Source and Drain, and the current between source and drain is modulated by changing the grid voltage.MOSFET (metal oxide semiconductor field effect transistor) is a special type of FET, which plays an important role in electronic design because of its high input impedance, low noise and low power consumption. Mosfet-single also refers to a single MOSFET element or a simple circuit unit with it as the core, which further improves performance stability and application range on the basis of retaining the basic characteristics of FET.

FAQ about Transistors - FETs, MOSFETs - Single

  • 1. How does a MOSFET work in an inverter?

    In an inverter, a MOSFET is used as a switching element, quickly turning the circuit on or off according to the control signal, thereby converting DC power to AC power.

  • 2. What role does a MOSFET play in a motor?

    MOSFETs are often used for functions such as speed control, direction control, and soft start/stop of motors. They can respond quickly to control signals and provide precise current control.

  • 3. Do MOSFETs work in AC or DC?

    MOSFETs can work in both DC and AC circuits, depending on the specific application requirements.
