FX22-80S-0.5SH

Hirose Electric Co Ltd FX22-80S-0.5SH

The picture is for reference only, please refer to the product specification

  • FX22-80S-0.5SH
  • Hirose Electric Co Ltd
  • CONN RCPT 0.5MM 80POS RA SMD
  • Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
  • FX22-80S-0.5SH Datasheet
  • -
  • -
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 19550
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is FX22-80S-0.5SH

Hirose Electric Co Ltd Part Number FX22-80S-0.5SH（Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)）, developed and manufactured by Hirose Electric Co Ltd, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

FX22-80S-0.5SH is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

FX22-80S-0.5SH Specifications

  • Part NumberFX22-80S-0.5SH
  • CategoryRectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
  • ManufacturerHirose Electric Co Ltd
  • DescriptionCONN RCPT 0.5MM 80POS RA SMD
  • Package-
  • SeriesFunctionMax? FX22
  • FeaturesBoard Guide
  • Mounting TypeSurface Mount, Right Angle
  • Number of Positions80
  • Pitch0.020" (0.50mm)
  • Height Above Board0.165" (4.20mm)
  • Connector TypeReceptacle, Non-Gendered
  • Number of Rows1

Application of FX22-80S-0.5SH

Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) are widely used in electronic devices and systems requiring high-density and high-speed connections. In communication equipment, they are used in core equipment such as high-speed backplanes, switches and routers; In computing, such connectors are a key component in building high-performance computing platforms that support multi-processor parallel computing and high-speed memory access. In addition, in the fields of industrial automation, medical equipment, aerospace and automotive electronics, rectangular link-arrays, edge types, and sandwich types are also favored for their excellent electrical performance and reliability, and are used to achieve precise connection and control of complex circuit systems.

FX22-80S-0.5SH Datasheet

FX22-80S-0.5SH Datasheet , FunctionMax? FX22,Board Guide,Surface Mount, Right Angle,80,0.020" (0.50mm),0.165" (4.20mm),Receptacle, Non-Gendered,1

FX22-80S-0.5SH Classification

Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)

Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) are three different forms of rectangular connectors. Array type rectangular connectors usually refer to their internal contact pairs (that is, pins and terminals) arranged in array form, which is conducive to high-density connection, suitable for occasions where a large number of signals or data need to be transmitted. A marginal rectangular connector is a part of the edge of the circuit board that is connected, usually through pins or slots, to a gold finger or pad on the edge of the circuit board. The sandwich type (board-to-board) rectangular connector is specially designed to connect between two or more circuit boards. It directly connects the power supply and signal between the printed circuit board through the pin of the connector to achieve an efficient and stable electrical connection.

FAQ about Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)

  • 1. Types of rectangular connectors?

    1. In the past, it was mainly produced by enterprises under the Ministry of Electronics Industry, such as CA, CB, and CD rectangular connectors.
    2. Now it is more commonly used, mainly produced by enterprises under the Ministry of Electronics.
    3. J-type rectangular connectors, mainly produced by enterprises under the Ministry of Aviation and Aerospace.
    4. Rectangular connectors produced according to the national military standard (GJB).
    5. Rectangular connectors produced according to the International Electrotechnical Commission (IEC) standard.

  • 2. Operation Guide for Rectangular Connectors?

    1. To ensure reliable connection of the product, ensure that the connector is properly plugged in during use. Do not forcefully insert if any abnormality is found during insertion.
    2. Connectors that are not fully inserted or not locked cannot be powered on.
    3. The derating of the main technical parameters of the product (see the rectangular connector product sample manual) should be clarified according to different application conditions to improve the reliability of use.
    4. The rectangular electrical connector is a short-shell connector that does not have the function of preventing oblique insertion. When inserting, the direction should be aligned first and then pushed in slowly, because it takes time for the twist needle to automatically find the correct position. It is recommended to observe with your eyes when plugging or separating the connector, operate carefully, prevent the product from being excessively deflected, and try not to use the left and right shaking method to pull it out. In particular, excessive deflection at the moment of plugging or separating should be avoided, otherwise it may cause damage to the pins, sockets, shells and other parts.
    5. During use, the root of the cable should be avoided from being stressed to prevent the cable from coming out or breaking.
    6. For sealed rectangular electrical connector products supported by glass insulators, the welding terminals should not be moved arbitrarily during welding, and they should not be shaken left and right when unplugged. Also, be careful to handle with care.
    7. For applications where plugging and unplugging are frequent, converters, transfer cables or anti-slant plug connectors can be used when necessary.
    8. For connectors that require soldering, damage to the connector due to excessive soldering iron temperature or long soldering time should be avoided.
    9. The connector should be plugged in or dust-proof when placed.
    10. The accessories of the connector should be installed with matching installation tools to avoid excessive torque damaging the screws or nuts. When the installation accessories need to be prevented from loosening, it is recommended to take necessary measures to prevent loosening (such as adding elastic washers, etc.).

  • 3. Application fields of rectangular industrial connectors?

    1. Industrial fields: automated numerical control, hot runner molds, injection molding machines, etc.;
    2. Machinery industry: robotics industry, engineering automation, automotive industry, escalators, elevators, printing industry, textile industry, engineering machinery, lathes, plastic processing machinery, metal processing and wood processing machinery, food and beverage processing and packaging machinery;
    3. Energy industry: power industry, wind energy industry;
    4. Transportation technology: railway transportation, etc.
