RBB30DHHN

Sullins Connector Solutions RBB30DHHN

The picture is for reference only, please refer to the product specification

  • RBB30DHHN
  • Sullins Connector Solutions
  • CONN EDGE DUAL FMALE 60POS 0.050
  • Card Edge Connectors - Edgeboard Connectors
  • RBB30DHHN Datasheet
  • -
  • -
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 22532
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is RBB30DHHN

Sullins Connector Solutions Part Number RBB30DHHN（Card Edge Connectors - Edgeboard Connectors）, developed and manufactured by Sullins Connector Solutions, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

RBB30DHHN is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

RBB30DHHN Specifications

  • Part NumberRBB30DHHN
  • CategoryCard Edge Connectors - Edgeboard Connectors
  • ManufacturerSullins Connector Solutions
  • DescriptionCONN EDGE DUAL FMALE 60POS 0.050
  • Package-
  • Series-
  • Operating Temperature-65°C ~ 125°C
  • Mounting TypeThrough Hole
  • TerminationSolder, Staggered
  • Contact MaterialPhosphor Bronze
  • Contact FinishGold
  • ColorBlack
  • Number of Positions60
  • Pitch0.050" (1.27mm)
  • Contact Finish Thickness10µin (0.25µm)
  • Number of Rows2
  • GenderFemale
  • Contact TypeHairpin Bellows
  • Card Thickness0.062" (1.57mm)
  • Card TypeNon Specified - Dual Edge
  • Number of Positions/Bay/Row30

Application of RBB30DHHN

Card Edge Connectors - Edgeboard Connectors - have a wide range of applications in many fields. In the computer field, it is a key component of the expansion slots (such as PCI, PCIe slots) on the motherboard, which are used to connect expansion cards such as video cards, sound cards, network cards, and improve the performance and functions of the computer. In the field of communication, it is widely used in network equipment such as switches and routers to ensure high-speed data transmission and stable operation of equipment. In addition, in high-end fields such as industrial automation, medical equipment, aerospace, card edge linkers-edge plate connectors also play an important role, providing reliable support for the electrical connection of various precision equipment. These areas have extremely high performance requirements for connectors, requiring them to maintain stable electrical connections and signal transmission quality in harsh environments.

RBB30DHHN Datasheet

RBB30DHHN Datasheet , -65°C ~ 125°C,Through Hole,Solder, Staggered,Phosphor Bronze,Gold,Black,60,0.050" (1.27mm),10µin (0.25µm),2,Female,Hairpin Bellows,0.062" (1.57mm),Non Specified - Dual Edge,30

RBB30DHHN Classification

Card Edge Connectors - Edgeboard Connectors

Card Edge Connectors - Edgeboard Connectors are specialized connectors used to connect expansion cards to the host board or backplane. This connector typically has a series of parallel metal contacts that are located on the edge of the expansion card, and when the expansion card is inserted into the host board or backplane, these contacts make contact with the corresponding connector contacts to form an electrical connection.

FAQ about Card Edge Connectors - Edgeboard Connectors

  • 1. What materials are used in card edge connectors?

    Contacts are typically made of phosphor bronze or beryllium copper, with gold or tin plating for enhanced conductivity and corrosion resistance.

  • 2. What are the different types of card edge connectors?

    Standard edge connectors: For general-purpose PCBs.

    High-speed edge connectors: For data-intensive applications.

    Power edge connectors: Designed for high-current applications.

  • 3. How do you choose the right card edge connector?

    Consider factors such as pitch size, number of contacts, current rating, mounting style, and application requirements.
