Semtech Corporation SC4540ULTRT
The picture is for reference only, please refer to the product specification
- SC4540ULTRT
- Semtech Corporation
- IC LED DRVR RGLTR DIM 30MA 8MLPD
- PMIC - LED Drivers
- SC4540ULTRT Datasheet
- 8-UFDFN Exposed Pad
- Tape & Reel (TR)
-
Lead free / RoHS Compliant - 14053
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is SC4540ULTRT
Semtech Corporation Part Number SC4540ULTRT（PMIC - LED Drivers）, developed and manufactured by Semtech Corporation, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
SC4540ULTRT is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
SC4540ULTRT Specifications
- Part NumberSC4540ULTRT
- CategoryPMIC - LED Drivers
- ManufacturerSemtech Corporation
- DescriptionIC LED DRVR RGLTR DIM 30MA 8MLPD
- PackageTape & Reel (TR)
- Series-
- TypeDC DC Regulator
- Operating Temperature-40°C ~ 85°C (TA)
- Mounting TypeSurface Mount
- Package / Case8-UFDFN Exposed Pad
- Supplier Device Package8-MLPD-UT (2x2)
- TopologyStep-Up (Boost)
- ApplicationsBacklight
- Number of Outputs1
- Voltage - Output5V ~ 38V
- Frequency800kHz
- Current - Output / Channel30mA
- Internal Switch(s)Yes
- DimmingPWM
- Voltage - Supply (Max)12V
- Voltage - Supply (Min)2.8V
Application of SC4540ULTRT
SC4540ULTRT Datasheet
SC4540ULTRT Datasheet , Tape & Reel (TR),DC DC Regulator,-40°C ~ 85°C (TA),Surface Mount,8-UFDFN Exposed Pad,8-MLPD-UT (2x2),Step-Up (Boost),Backlight,1,5V ~ 38V,800kHz,30mA,Yes,PWM,12V,2.8V
SC4540ULTRT Classification
PMIC - LED Drivers
FAQ about PMIC - LED Drivers
-
1. What is the difference between an LED driver and a ballast?
LED drivers: Designed specifically for LEDs, they are usually used to adjust the output current to meet the requirements of LEDs.
Ballasts: Traditionally used for fluorescent lamps or other gas discharge lamps, they control the high voltage at startup and limit the operating current. Although some modern electronic ballasts can also provide constant current, their original design and application areas are different from LED drivers. -
2. Can I run an LED without a driver?
Yes, but additional circuits (such as resistors) are required to limit the current. However, this method is less efficient and difficult to maintain a stable current, which may lead to poor LED performance or shortened life.
-
3. Why do I need to program an LED driver?
Programming is usually for advanced drivers with programmable functions, such as achieving finer dimming control, color adjustment or other intelligent functions. This allows users to customize the behavior of the driver according to specific needs.
