KEMET VE1210M301R006
The picture is for reference only, please refer to the product specification
- VE1210M301R006
- KEMET
- VARISTOR 11V 300A 1210
- TVS - Varistors, MOVs
- VE1210M301R006 Datasheet
- 1210 (3225 Metric)
- 1210 (3225 Metric)
-
Lead free / RoHS Compliant - 13092
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is VE1210M301R006
KEMET Part Number VE1210M301R006（TVS - Varistors, MOVs）, developed and manufactured by KEMET, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
VE1210M301R006 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
VE1210M301R006 Specifications
- Part NumberVE1210M301R006
- CategoryTVS - Varistors, MOVs
- ManufacturerKEMET
- DescriptionVARISTOR 11V 300A 1210
- Package1210 (3225 Metric)
- SeriesAutomotive, AEC-Q200, VE
- Mounting TypeSurface Mount
- Package / Case1210 (3225 Metric)
- Number of Circuits1
- Varistor Voltage (Typ)11V
- Current - Surge300A
- Maximum DC Volts8V
- Varistor Voltage (Min)8.8V
- Varistor Voltage (Max)13.2V
- Maximum AC Volts6V
- Energy0.80J
Application of VE1210M301R006
VE1210M301R006 Datasheet
VE1210M301R006 Datasheet , 1210 (3225 Metric),Automotive, AEC-Q200, VE,Surface Mount,1210 (3225 Metric),1,11V,300A,8V,8.8V,13.2V,6V,0.80J
VE1210M301R006 Classification
TVS - Varistors, MOVs
FAQ about TVS - Varistors, MOVs
-
1. What are Movs?
Movs(Move String) is an instruction cluster in assembly language, mainly used to copy strings. The Movs instruction cluster includes multiple variants for handling data movement operations of different lengths.
Basic Functions
The main function of the Movs instruction is to copy the data of the DSSI address to the ESDI address. Specifically:
MOVSB: Move one byte at a time.
MOVSW: Move one word (usually two bytes) at a time.
MOVSD: Move one double word (usually four bytes) at a time.
-
2. What is the use of MOV varistor?
MOV varistor (Metal-Oxide Varistor, referred to as MOV) is mainly used for overvoltage protection, especially in the fields of power electronics, communication electronics and industrial control.
Main use
Overvoltage protection: MOV varistors play the role of overvoltage protection in the circuit. They can quickly reduce their resistance value when voltage spikes or surges occur, thereby consuming surge energy and protecting other components in the circuit from damage.
Electrostatic protection: MOV varistors are often used for electrostatic protection, especially at the power input end, which can effectively prevent static electricity from damaging the circuit.
Lightning protection: By suppressing the surge voltage caused by lightning strikes, the equipment is protected from lightning strikes. -
3. What is the difference between TVS diodes and MOVs?
The main differences between TVS diodes and MOV varistors are the working principle, application scenarios and performance characteristics.
Working principle
T VS diode is a semiconductor device with nonlinear volt-ampere characteristics, and its working principle is based on the breakdown phenomenon of PN junction. When TVS diode is subjected to reverse transient high voltage, its impedance drops rapidly, absorbing most of the energy and clamping the voltage at a safe value, thereby protecting electronic components 12. TVS diode has a small leakage current before breakdown, and it behaves as a voltage regulator after breakdown, with a strong voltage clamping ability.
MOV varistor is a multi-layer structure made of zinc oxide material with a multi-grain structure, which absorbs surge current by changing the conduction resistance. When the voltage exceeds its varistor voltage, the resistance of MOV drops rapidly, shunting the current, thereby protecting the subsequent circuit 45. MOV has a higher clamping voltage when the current is too large, and a larger leakage current when the voltage is low.
