Renesas Electronics America Inc X9118TV14Z-2.7
The picture is for reference only, please refer to the product specification
- X9118TV14Z-2.7
- Renesas Electronics America Inc
- IC XDCP SGL 1024TAP 100K 14TSSOP
- Digital Potentiometers ICs
- X9118TV14Z-2.7 Datasheet
- 14-TSSOP (0.173\", 4.40mm Width)
- Tube
-
Lead free / RoHS Compliant - 3660
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is X9118TV14Z-2.7
Renesas Electronics America Inc Part Number X9118TV14Z-2.7（Digital Potentiometers ICs）, developed and manufactured by Renesas Electronics America Inc, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
X9118TV14Z-2.7 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
X9118TV14Z-2.7 Specifications
- Part NumberX9118TV14Z-2.7
- CategoryDigital Potentiometers ICs
- ManufacturerRenesas Electronics America Inc
- DescriptionIC XDCP SGL 1024TAP 100K 14TSSOP
- PackageTube
- SeriesXDCP™
- Features-
- Interface-
- Voltage - Supply2.7V ~ 5.5V
- Operating Temperature0°C ~ 70°C
- Mounting TypeSurface Mount
- Package / Case14-TSSOP (0.173\", 4.40mm Width)
- Supplier Device Package14-TSSOP
- Tolerance-
- Number of Circuits1
- Configuration-
- Memory TypeNon-Volatile
- Taper-
- Number of Taps1024
- Resistance (Ohms)100k
- Temperature Coefficient (Typ)±300ppm/°C
- Resistance - Wiper (Ohms) (Typ)-
Application of X9118TV14Z-2.7
X9118TV14Z-2.7 Datasheet
X9118TV14Z-2.7 Datasheet , Tube,XDCP™,2.7V ~ 5.5V,0°C ~ 70°C,Surface Mount,14-TSSOP (0.173\", 4.40mm Width),14-TSSOP,1,Non-Volatile,1024,100k,±300ppm/°C
X9118TV14Z-2.7 Classification
Digital Potentiometers ICs
FAQ about Digital Potentiometers ICs
-
1. What is the difference between IC and digital IC?
The main difference between IC and digital IC is that they process different types of signals. IC processes continuously changing analog signals, while digital IC processes discrete digital signals.
Specifically, IC (integrated circuit) is a microelectronic device or component that uses a certain process to interconnect transistors, resistors, capacitors and other components and wiring, and is made on a small piece of semiconductor wafer, and then packaged to form a circuit with specific functions. Integrated circuits have the advantages of small size, light weight, long life and high reliability.
Digital IC specializes in processing digital signals, which are discrete in time and amplitude. The design focus of digital IC is on the optimization of logical relationships and system architecture, pursuing the smallest line width, lowest power consumption and fastest transmission speed. Examples of digital ICs include CPUs, microprocessors, microcontrollers, etc., which are widely used in computers and other digital systems. -
2. How to use digital potentiometers?
Digital potentiometers are a new type of CMOS digital and analog mixed signal processing integrated circuit that replaces traditional mechanical potentiometers. It is controlled by digital inputs, produces an analog output, and has precise resistance adjustment functions.
The basic components of digital potentiometers include voltage dividers and controllers. The voltage divider consists of a series of resistor elements that divide the input voltage according to a certain ratio; the controller is responsible for reading the control signal and opening or closing the corresponding switch according to the high or low signal, thereby changing the size of the total resistance.
When using a digital potentiometer, you first need to make a hardware connection. For example, connect the encoding mode of the EC11 digital potentiometer to a specific pin of the timer. Then, the mode of the encoder is controlled by software to adjust the digital potentiometer. The specific operations include entering the potentiometer mode, adjusting the value, and saving the setting. -
3. What is the principle of the digital potentiometer?
A digital potentiometer is a potentiometer that uses digital signals to control the resistance value. It switches between different resistance values through the input digital signal to adjust the circuit parameters. The digital potentiometer mainly consists of a voltage divider and a controller. The voltage divider consists of a series of resistor elements. The controller is responsible for reading the control signal and opening or closing the corresponding switch according to the high or low signal, thereby changing the size of the total resistance.
The working principle of the digital potentiometer is based on the resistor ladder structure. The internal resistor ladder structure is adopted. Each resistor element on the ladder is equipped with a switch to control whether the resistor is connected to the circuit. When the controller receives a binary signal, it will choose to open or close the corresponding switch according to the value of the signal. For example, when a certain bit in the binary signal is 1, the corresponding switch is opened and the resistor element is connected to the circuit; if the bit is 0, the switch is closed and the resistor element is disconnected. Through the combination of multiple binary signals, the total resistance value in the circuit can be accurately adjusted.
Digital potentiometers have many advantages, such as high accuracy and stability, and are insensitive to dust, dirt and moisture, which makes them more reliable than traditional mechanical potentiometers in many applications. In addition, digital potentiometers are available in two types: volatile and non-volatile, suitable for different application scenarios.
