EFR(02)-240X240T0800

KEMET EFR(02)-240X240T0800

The picture is for reference only, please refer to the product specification

  • EFR(02)-240X240T0800
  • KEMET
  • FLEX SUPP. SHEET 240X240X0.2
  • RFI and EMI - Shielding and Absorbing Materials
  • EFR(02)-240X240T0800 Datasheet
  • -
  • -
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 23286
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is EFR(02)-240X240T0800

KEMET Part Number EFR(02)-240X240T0800（RFI and EMI - Shielding and Absorbing Materials）, developed and manufactured by KEMET, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

EFR(02)-240X240T0800 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

EFR(02)-240X240T0800 Specifications

  • Part NumberEFR(02)-240X240T0800
  • CategoryRFI and EMI - Shielding and Absorbing Materials
  • ManufacturerKEMET
  • DescriptionFLEX SUPP. SHEET 240X240X0.2
  • Package-
  • SeriesEFR
  • TypeAbsorbing Sheet
  • Operating Temperature-40°C ~ 105°C
  • ShapeSquare
  • Length9.449" (240.00mm)
  • Width9.449" (240.00mm)
  • Thickness - Overall0.009" (0.23mm)
  • AdhesiveNon-Conductive, Single Sided
  • MaterialPolymer Resin, Magnetic Powder

Application of EFR(02)-240X240T0800

RFI and EMI Shielding and Absorbing Materials are widely used in various situations where electromagnetic interference suppression is required. In the field of consumer electronics products, such as smartphones, tablets, laptops, and other devices, these materials can protect sensitive circuit boards from external electromagnetic fields. In communication devices such as base stations, routers, and switches, shielding and absorbing materials help ensure the quality and stability of data transmission. In the field of automotive electronics, with the increase of electronic systems in vehicles, these materials are crucial for ensuring driving safety. In the aerospace and defense industries, these materials are even more essential as they can protect precision instruments from electromagnetic interference under harsh environmental conditions. In addition, shielding and absorbing materials also play an important role in industries such as medical equipment, industrial automation, and rail transit, ensuring the normal operation and efficient performance of electronic systems.

EFR(02)-240X240T0800 Datasheet

EFR(02)-240X240T0800 Datasheet , EFR,Absorbing Sheet,-40°C ~ 105°C,Square,9.449" (240.00mm),9.449" (240.00mm),0.009" (0.23mm),Non-Conductive, Single Sided,Polymer Resin, Magnetic Powder

EFR(02)-240X240T0800 Classification

RFI and EMI - Shielding and Absorbing Materials

RFI and EMI Shielding and Absorbing Materials are materials specifically designed to reduce or eliminate radio frequency interference (RFI) and electromagnetic interference (EMI). These materials mainly include two parts: shielding materials and absorbing materials. Shielding materials are usually in the form of metal foil, conductive coating, or metal mesh, which can reflect or guide electromagnetic waves away from sensitive electronic devices to prevent interference. Absorbent materials are composed of ferrite cores, carbon fibers, conductive polymers, etc. They can absorb and convert electromagnetic waves that cannot be blocked by shielding materials into thermal energy. These materials have good electromagnetic compatibility, which can effectively reduce electromagnetic interference levels and improve the stability and reliability of electronic devices.

FAQ about RFI and EMI - Shielding and Absorbing Materials

  • 1. What are the typical applications of RFI and EMI shielding materials?

    Consumer electronics: Protect circuits in phones, tablets, and laptops.

    Automotive systems: Prevent interference in electric vehicles and sensors.

    Medical devices: Shield sensitive equipment like MRI machines.

    Military and aerospace: Ensure reliability in radar and communication systems.

  • 2. What factors influence the selection of shielding materials?

    Frequency range: The effectiveness depends on the material's ability to block specific frequencies.

    Conductivity and permeability: Higher values improve shielding performance.

    Environment: Resistance to corrosion, heat, or chemicals may be necessary.

    Weight and flexibility: Important for mobile and compact devices.

  • 3. What is the role of gaskets and seals in EMI shielding?

    Gaskets and seals ensure continuous contact between shielded components, preventing leaks in electromagnetic enclosures. Common materials include conductive elastomers and fabric-over-foam.
