Texas Instruments ISO5452QDWQ1
- ISO5452QDWQ1
- Texas Instruments
- DGTL ISO 5.7KV GATE DRVR 16SOIC
- Isolators - Gate Drivers
- ISO5452QDWQ1 Datasheet
- 16-SOIC (0.295", 7.50mm Width)
- 16-SOIC (0.295", 7.50mm Width)
- Lead free / RoHS Compliant
- 3714
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
Part Number ISO5452QDWQ1 |
Category Isolators - Gate Drivers |
Manufacturer Texas Instruments |
Description DGTL ISO 5.7KV GATE DRVR 16SOIC |
Package 16-SOIC (0.295", 7.50mm Width) |
Series Automotive, AEC-Q100 |
Voltage - Supply 15 V ~ 30 V |
Operating Temperature -40°C ~ 125°C |
Mounting Type Surface Mount |
Package / Case 16-SOIC (0.295", 7.50mm Width) |
Supplier Device Package 16-SOIC |
Number of Channels 1 |
Technology Capacitive Coupling |
Voltage - Isolation 5700Vrms |
Current - Peak Output 2.7A, 5.5A |
Approvals CQC, CSA, TUV, UL, VDE |
Common Mode Transient Immunity (Min) 50kV/µs |
Propagation Delay tpLH / tpHL (Max) 110ns, 110ns |
Rise / Fall Time (Typ) 18ns, 20ns |
Current - Output High, Low 1.5A, 3.4A |
Package_case 16-SOIC (0.295", 7.50mm Width) |
