PRTR5V0U2AX/S911,2

Nexperia USA Inc. PRTR5V0U2AX/S911,2

The picture is for reference only, please refer to the product specification

  • PRTR5V0U2AX/S911,2
  • Nexperia USA Inc.
  • TVS DIODE 5.5VWM SOT143
  • TVS - Diodes
  • PRTR5V0U2AX/S911,2 Datasheet
  • TO-253-4, TO-253AA
  • TO-253-4, TO-253AA
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 23434
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is PRTR5V0U2AX/S911,2

Nexperia USA Inc. Part Number PRTR5V0U2AX/S911,2（TVS - Diodes）, developed and manufactured by Nexperia USA Inc., distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

PRTR5V0U2AX/S911,2 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

PRTR5V0U2AX/S911,2 Specifications

  • Part NumberPRTR5V0U2AX/S911,2
  • CategoryTVS - Diodes
  • ManufacturerNexperia USA Inc.
  • DescriptionTVS DIODE 5.5VWM SOT143
  • PackageTO-253-4, TO-253AA
  • SeriesAutomotive, AEC-Q101
  • TypeSteering (Rail to Rail)
  • Operating Temperature-40°C ~ 85°C (TA)
  • Mounting TypeSurface Mount
  • Package / CaseTO-253-4, TO-253AA
  • Supplier Device PackageSOT-143B
  • ApplicationsAutomotive
  • Unidirectional Channels2
  • Voltage - Reverse Standoff (Typ)5.5V (Max)
  • Voltage - Breakdown (Min)6V
  • Power Line ProtectionYes
  • Capacitance @ Frequency1.8pF @ 1MHz

Application of PRTR5V0U2AX/S911,2

TVS - Diodes play a vital role in the design of electronic products, and its application fields are very wide. In the field of consumer electronics, such as smartphones, tablets, televisions, etc., TVS diodes are used to protect internal integrated circuits from electrostatic discharge and power fluctuations. In the field of industrial automation, they are used to protect critical equipment such as motor drives and PLC (programmable logic controllers) to ensure the stable operation of production lines. In addition, TVS diodes are also essential components in automotive electronic systems, which can protect on-board electronic systems from transient voltages caused by engine ignition, load mutations, etc. In the field of communication and data transmission, TVS diodes are also used to protect signal transmission lines to ensure the integrity and reliability of data transmission. In general, TVS diodes, with their excellent transient voltage protection capabilities, play an irreplaceable role in ensuring the safe and stable operation of electronic equipment.

PRTR5V0U2AX/S911,2 Datasheet

PRTR5V0U2AX/S911,2 Datasheet , TO-253-4, TO-253AA,Automotive, AEC-Q101,Steering (Rail to Rail),-40°C ~ 85°C (TA),Surface Mount,TO-253-4, TO-253AA,SOT-143B,Automotive,2,5.5V (Max),6V,Yes,1.8pF @ 1MHz

PRTR5V0U2AX/S911,2 Classification

TVS - Diodes

TVS - Diodes are electronic components designed to protect circuits from transient overvoltage damage. They protect other sensitive components in the circuit from damage by quickly switching on and directing excess transient voltage to ground or power supply. TVS diodes are typically constructed of PN junction or metal oxide semiconductor structures with extremely fast response times and low clamping voltage characteristics. Its design principle is based on the avalanche breakdown effect, that is, when a specific voltage threshold is reached, the diode will rapidly change from a high resistance state to a low resistance state, limiting the transient voltage to a safe level. TVS diodes are used in a wide variety of electronic devices, especially those that need to protect critical circuits from lightning strikes, electrostatic discharges, or other transient voltage events.

FAQ about TVS - Diodes

  • 1. What does a TVS diode do?

    The main function of TVS diodes (Transient Voltage Suppression Diodes) is to protect electronic equipment from voltage spikes and surge voltages‌. When the two poles of the TVS diode are impacted by reverse transient high energy, it can change the high impedance between the two poles into low impedance within 10^-12 seconds, while absorbing surge power up to several kilowatts, causing the gap between the two poles to The voltage is clamped to a safe value, thereby effectively protecting precision components in electronic circuits.
    The specific working principle of TVS diodes is as follows:
    Absorb surge power‌: TVS diodes can, under reverse application conditions, when subjected to a high-energy large pulse, their working impedance immediately drops to a lower conduction state, allowing large current to pass while clamping the voltage at predetermined level. Its response time is only 10^-12 seconds.
    Protection circuit: TVS diodes are used in parallel with the protected circuit. When the circuit is working normally, the TVS diode is in a high impedance state and does not affect the circuit; when there is a surge voltage impact, the TVS diode conducts quickly, absorbs the surge energy, and protects the subsequent circuit.


  • 2. What is the difference between TVS and ESD diodes?

    The main difference between TVS diodes and ESD diodes is their working principle, application scenarios and characteristics.
    Working principle and application scenarios
    TVS diodes (Transient Voltage Suppressors): TVS diodes are mainly used to suppress transient voltages and prevent components in the circuit from being damaged by surge voltages. When the two poles of the TVS diode are impacted by reverse transient high energy, it can change the high impedance to low impedance in a very short time, absorb the surge power, and protect the precision components in the circuit‌1. TVS diodes are suitable for protection against various surge pulses, such as lightning strikes, large-capacity load switching, etc.
    ESD diode (Electro-Static discharge): ESD diode is mainly used to prevent static electricity and prevent damage to electronic equipment caused by electrostatic discharge. ESD diodes have low capacitance values, typically between 1 and 3.5 picofarad (PF), to accommodate the rapid changes in electrostatic discharge. ESD diodes are suitable for board-level protection, especially in high-speed USB and I/O interfaces, which have higher requirements for electrostatic discharge.

  • 3. How do TVS diodes fail?

    The failure modes of TVS diodes mainly include short circuit failure, open circuit failure and performance degradation‌. These failure modes can have a serious impact on the normal operation and protection functions of the circuit.
    short circuit fault
    Short circuit failure is one of the most common failure modes of TVS diodes. When a TVS diode is short-circuited, it changes to a low-impedance state, allowing a large amount of current to pass through, which may cause the circuit to not function properly and may even damage other circuit components. Causes of short circuit faults include:
    Thermal breakdown: In a high temperature environment or when subjected to excessive transient energy impact, the PN junction of the TVS diode may undergo thermal breakdown, resulting in a short circuit.
    Over-electrical stress: When the transient pulse energy exceeds the energy that the TVS can withstand, it will cause over-electrical stress damage and even directly cause burnout.
    Manufacturing process issues: Such as chip bonding interface voids, mesa defects, strong accumulation layer or strong inversion layer on the surface, chip cracks, uneven impurity diffusion, etc., which may cause short circuit failures of TVS diodes during manufacturing or use.
