Richtek USA Inc. R7731AGE
The picture is for reference only, please refer to the product specification
- R7731AGE
- Richtek USA Inc.
- IC OFFLINE SW FLYBACK SOT23-6
- PMIC - AC DC Converters, Offline Switchers
- R7731AGE Datasheet
- SOT-23-6
- -Reel®
-
Lead free / RoHS Compliant - 3306
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is R7731AGE
Richtek USA Inc. Part Number R7731AGE（PMIC - AC DC Converters, Offline Switchers）, developed and manufactured by Richtek USA Inc., distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
R7731AGE is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
R7731AGE Specifications
- Part NumberR7731AGE
- CategoryPMIC - AC DC Converters, Offline Switchers
- ManufacturerRichtek USA Inc.
- DescriptionIC OFFLINE SW FLYBACK SOT23-6
- Package-Reel®
- Series-
- Operating Temperature-40°C ~ 85°C (TA)
- Mounting TypeSurface Mount
- Package / CaseSOT-23-6
- Supplier Device PackageSOT-23-6
- TopologyFlyback
- Voltage - Supply (Vcc/Vdd)12V ~ 25V
- Frequency - Switching65kHz
- Control Features-
- Power (Watts)-
- Voltage - Breakdown-
- Internal Switch(s)No
- Output IsolationIsolated
- Voltage - Start Up14 V
- Duty Cycle75%
- Fault ProtectionCurrent Limiting, Over Load, Over Temperature, Over Voltage
Application of R7731AGE
R7731AGE Datasheet
R7731AGE Datasheet , -Reel®,-40°C ~ 85°C (TA),Surface Mount,SOT-23-6,SOT-23-6,Flyback,12V ~ 25V,65kHz,No,Isolated,14 V,75%,Current Limiting, Over Load, Over Temperature, Over Voltage
R7731AGE Classification
PMIC - AC DC Converters, Offline Switchers
FAQ about PMIC - AC DC Converters, Offline Switchers
-
1. How does an AC/DC converter work?
An AC/DC converter converts AC to DC through a rectifier circuit, and after filtering and voltage stabilization, it finally provides a stable DC output. Offline switching power supplies also use switching regulation technology to improve efficiency.
-
2. What factors should be considered when selecting an AC/DC converter?
Factors such as input voltage range, output voltage and current requirements, power efficiency, packaging, temperature range, reliability and safety certification need to be considered when selecting.
-
3. Are offline switching power supplies suitable for high power applications?
Offline switching power supplies can be used for high power applications, but proper heat dissipation and power management solutions must be designed to ensure conversion efficiency and stability. Choosing a suitable topology such as LLC resonant converter can also help achieve high power output.
