Texas Instruments TLC2554IPW
The picture is for reference only, please refer to the product specification
- TLC2554IPW
- Texas Instruments
- IC ADC 12BIT SAR 16TSSOP
- Data Acquisition - Analog to Digital Converters (ADC)
- TLC2554IPW Datasheet
- 16-TSSOP (0.173\", 4.40mm Width)
- Tube
-
Lead free / RoHS Compliant - 1570
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is TLC2554IPW
Texas Instruments Part Number TLC2554IPW（Data Acquisition - Analog to Digital Converters (ADC)）, developed and manufactured by Texas Instruments, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
TLC2554IPW is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
TLC2554IPW Specifications
- Part NumberTLC2554IPW
- CategoryData Acquisition - Analog to Digital Converters (ADC)
- ManufacturerTexas Instruments
- DescriptionIC ADC 12BIT SAR 16TSSOP
- PackageTube
- Series-
- Features-
- Operating Temperature-40°C ~ 85°C
- Mounting TypeSurface Mount
- Package / Case16-TSSOP (0.173\", 4.40mm Width)
- Supplier Device Package16-TSSOP
- Reference TypeExternal, Internal
- Sampling Rate (Per Second)400k
- Data InterfaceSPI
- Number of Bits12
- Voltage - Supply, Analog5V
- Voltage - Supply, Digital5V
- Number of Inputs3, 4
- Input TypePseudo-Differential, Single Ended
- ConfigurationMUX-S/H-ADC
- Ratio - S/H:ADC1:1
- Number of A/D Converters1
- ArchitectureSAR
Application of TLC2554IPW
TLC2554IPW Datasheet
TLC2554IPW Datasheet , Tube,-40°C ~ 85°C,Surface Mount,16-TSSOP (0.173\", 4.40mm Width),16-TSSOP,External, Internal,400k,SPI,12,5V,5V,3, 4,Pseudo-Differential, Single Ended,MUX-S/H-ADC,1:1,1,SAR
TLC2554IPW Classification
Data Acquisition - Analog to Digital Converters (ADC)
FAQ about Data Acquisition - Analog to Digital Converters (ADC)
-
1. How does ADC convert analog to digital?
The technology that converts analog sound signals into digital signals is called analog-to-digital conversion technology (Analog to Digital Converter, referred to as ADC). The function of ADC is to convert continuously changing analog signals into discrete digital signals. The process of analog-to-digital conversion can be completed by steps such as sampling, holding, quantization, and encoding.
-
2. What is the main purpose of ADC?
The main purpose of ADC is to convert the input analog signal into a digital signal.
ADC, or analog-to-digital converter, is mainly used to convert continuously changing analog signals into discrete digital signals. The implementation process of ADC usually includes four steps: sampling, holding, quantization, and encoding.
-
3. When is ADC used?
ADC (Analog-to-Digital Converter) is widely used in a variety of scenarios, including but not limited to:
Sensor interface: For example, temperature sensors, pressure sensors, and light sensors, ADC converts analog voltages into digital signals for the use of digital thermometers, temperature control systems, barometers, air pressure sensing systems, light intensity detection and control systems.
Audio signal processing: In microphones, ADC converts analog audio signals into digital signals for digital audio processing, recording, and playback.
Medical equipment: Such as electrocardiograms (ECGs) and oximeters, ADC converts analog signals of ECG signals and blood oxygen saturation into digital signals for heart health monitoring and diagnosis and blood oxygen level monitoring.
Data acquisition system: In various applications that need to collect data from analog signals, ADC is used to convert analog signals into digital signals for storage, processing, and analysis.
