Texas Instruments UCC25701PWG4
The picture is for reference only, please refer to the product specification
- UCC25701PWG4
- Texas Instruments
- IC OFFLINE SW MULT TOP 14TSSOP
- PMIC - AC DC Converters, Offline Switchers
- UCC25701PWG4 Datasheet
- 14-TSSOP (0.173\", 4.40mm Width)
- Tube
-
Lead free / RoHS Compliant - 21283
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is UCC25701PWG4
Texas Instruments Part Number UCC25701PWG4（PMIC - AC DC Converters, Offline Switchers）, developed and manufactured by Texas Instruments, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
UCC25701PWG4 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
UCC25701PWG4 Specifications
- Part NumberUCC25701PWG4
- CategoryPMIC - AC DC Converters, Offline Switchers
- ManufacturerTexas Instruments
- DescriptionIC OFFLINE SW MULT TOP 14TSSOP
- PackageTube
- Series-
- Operating Temperature-55°C ~ 150°C (TJ)
- Mounting TypeSurface Mount
- Package / Case14-TSSOP (0.173\", 4.40mm Width)
- Supplier Device Package14-TSSOP
- TopologyBoost, Flyback, Forward
- Voltage - Supply (Vcc/Vdd)9V ~ 15V
- Frequency - Switching700kHz
- Control FeaturesSoft Start, Sync
- Power (Watts)-
- Voltage - Breakdown-
- Internal Switch(s)No
- Output IsolationIsolated
- Voltage - Start Up13 V
- Duty Cycle99%
- Fault ProtectionCurrent Limiting
