What is ZXTD720MCTA

Diodes Incorporated Part Number ZXTD720MCTA（Transistors - Bipolar (BJT) - Arrays）, developed and manufactured by Diodes Incorporated, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

ZXTD720MCTA is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

ZXTD720MCTA Specifications

  • Part NumberZXTD720MCTA
  • CategoryTransistors - Bipolar (BJT) - Arrays
  • ManufacturerDiodes Incorporated
  • DescriptionTRANS 2PNP 40V 3A 8DFN
  • Package-Reel®
  • Series-
  • Operating Temperature-55°C ~ 150°C (TJ)
  • Mounting TypeSurface Mount
  • Package / Case8-WDFN Exposed Pad
  • Supplier Device PackageDFN3020B-8
  • Power - Max1.7W
  • Transistor Type2 PNP (Dual)
  • Current - Collector (Ic) (Max)3A
  • Voltage - Collector Emitter Breakdown (Max)40V
  • Vce Saturation (Max) @ Ib, Ic370mV @ 250mA, 2.5A
  • Current - Collector Cutoff (Max)100nA
  • DC Current Gain (hFE) (Min) @ Ic, Vce60 @ 1.5A, 2V
  • Frequency - Transition190MHz

Application of ZXTD720MCTA

Bipolar (BJT) -Arrays are widely used in many fields. In the communication system, BJT-array can be used for RF amplification, signal modulation and demodulation, power amplification and other key links to improve the communication quality and transmission efficiency. In the field of automotive electronics, it is an important part of the engine control unit, body control module and other core components to achieve accurate control and optimization of vehicle systems. In addition, BJT-array is also widely used in industrial control, medical equipment, consumer electronics and other fields, such as the sensor interface circuit on the industrial automation production line, the signal amplification and processing circuit of medical equipment, the power management and drive circuit of household appliances.

ZXTD720MCTA Datasheet

ZXTD720MCTA Datasheet , -Reel®,-55°C ~ 150°C (TJ),Surface Mount,8-WDFN Exposed Pad,DFN3020B-8,1.7W,2 PNP (Dual),3A,40V,370mV @ 250mA, 2.5A,100nA,60 @ 1.5A, 2V,190MHz

ZXTD720MCTA Classification

Transistors - Bipolar (BJT) - Arrays

Bipolar (BJT) -Arrays is a circuit module that consists of multiple Bipolar Junction transistors (BJT) integrated together. This array design provides high power processing capabilities while maintaining good thermal management and control characteristics. BJT arrays typically include multiple NPN or PNP transistors that can be connected in series, parallel, or in combination to meet specific current and voltage requirements.
