Molex 0039532344
The picture is for reference only, please refer to the product specification
- 0039532344
- Molex
- CONN FFC TOP 34POS 1.25MM R/A
- FFC, FPC (Flat Flexible) Connectors
- 0039532344 Datasheet
- -
- -
-
Lead free / RoHS Compliant - 4599
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is 0039532344
Molex Part Number 0039532344（FFC, FPC (Flat Flexible) Connectors）, developed and manufactured by Molex, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
0039532344 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
0039532344 Specifications
- Part Number0039532344
- CategoryFFC, FPC (Flat Flexible) Connectors
- ManufacturerMolex
- DescriptionCONN FFC TOP 34POS 1.25MM R/A
- Package-
- Series5597
- FeaturesZero Insertion Force (ZIF)
- Operating Temperature-20°C ~ 80°C
- Mounting TypeThrough Hole, Right Angle
- TerminationSolder
- Contact MaterialPhosphor Bronze
- Contact FinishTin Bismuth
- Flat Flex TypeFFC, FPC
- Connector/Contact TypeContacts, Top
- Number of Positions34
- Pitch0.049" (1.25mm)
- FFC, FCB Thickness0.30mm
- Height Above Board0.197" (5.00mm)
- Locking FeatureSlide Lock
- Cable End TypeStraight
- Housing MaterialPolybutylene Terephthalate (PBT), Polyester
- Voltage Rating200V
- Material Flammability RatingUL94 V-0
- Actuator MaterialPolybutylene Terephthalate (PBT), Polyester
Application of 0039532344
0039532344 Datasheet
0039532344 Datasheet , 5597,Zero Insertion Force (ZIF),-20°C ~ 80°C,Through Hole, Right Angle,Solder,Phosphor Bronze,Tin Bismuth,FFC, FPC,Contacts, Top,34,0.049" (1.25mm),0.30mm,0.197" (5.00mm),Slide Lock,Straight,Polybutylene
0039532344 Classification
FFC, FPC (Flat Flexible) Connectors
FAQ about FFC, FPC (Flat Flexible) Connectors
-
1. What is FFC?
FFC (Flexible Flat Cable) is a flexible flat cable, usually composed of flat and soft conductors, such as tinned pure copper wire, made by high-temperature bonding of very thin and flexible adhesive film or paper film 1. FFC has the characteristics of flexibility, lightness, bendability, and anti-twisting. It is widely used in electronic devices as a bridge to connect various components, such as connecting displays and motherboards, touch screens and displays, battery components and control circuit boards. Due to its flexibility and bendability, FFC can achieve more flexible design, optimize the internal space of the device, and has the advantages of small size, light weight, and low cost.
-
2. What is the rated voltage of FFC?
The rated voltage of FFC is 300V.
FFC cable, also known as Flexible Flat Cable, is a flexible flat cable that is widely used in internal connections of electronic devices. Its main specifications and special features include:
Operating temperature: 80°C
Conductor: 32-16AWG (0.03-1.31mm²) tinned or bare copper strands
Insulation: PVC
Pitch: Common pitches are 0.5mm, 0.8mm, 1.0mm, 1.25mm, 1.27mm, 1.5mm, 2.0mm and 2.54mm
Acid and alkali resistance, oil resistance, heat resistance, moisture resistance, mildew resistance and other characteristics
FFC cables are widely used for data transmission between mobile parts and motherboards, between PCB boards and in miniaturized electrical equipment due to their small size, light weight and high flexibility.
-
3. What is the use of FFC cable?
FFC cable (Flexible Flat Cable) is mainly used to connect mobile parts with motherboards, PCB boards with PCB boards, and data transmission in miniaturized electrical equipment.
FFC cable has the following main features:
High flexibility: The number and spacing of wires can be arbitrarily selected, making wiring more convenient, greatly reducing the volume of electronic products, reducing production costs, and improving production efficiency.
Environmental resistance: It has anti-bending and anti-tensile functions, good flexibility, cold and high temperature resistance.
Wide application: It is suitable for use as a data transmission cable between mobile parts and motherboards, between PCB boards and PCB boards, and in miniaturized electrical equipment.
