What is 0520443345

Molex Part Number 0520443345（FFC, FPC (Flat Flexible) Connectors）, developed and manufactured by Molex, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

0520443345 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

0520443345 Specifications

  • Part Number0520443345
  • CategoryFFC, FPC (Flat Flexible) Connectors
  • ManufacturerMolex
  • DescriptionCONN FFC TOP 33POS 1.25MM R/A
  • Package-
  • Series52044
  • Operating Temperature-40°C ~ 85°C
  • Mounting TypeThrough Hole, Right Angle
  • TerminationKinked Pin
  • Contact MaterialPhosphor Bronze
  • Contact FinishTin
  • Flat Flex TypeFFC, FPC
  • Connector/Contact TypeContacts, Top
  • Number of Positions33
  • Pitch0.049" (1.25mm)
  • FFC, FCB Thickness0.30mm
  • Height Above Board0.197" (5.00mm)
  • Cable End TypeStraight
  • Housing MaterialPolybutylene Terephthalate (PBT), Polyester
  • Voltage Rating200V
  • Material Flammability RatingUL94 V-0

Application of 0520443345

FFC, FPC (Flat Flexible) Connectors) play an important role in several high-tech industries and applications due to their unique physical properties and high reliability. They are commonly found in consumer electronics, such as smartphones and tablets, to connect screens, cameras and other internal components; In the field of automotive electronics, FFC/FPC connectors are used for line connection of dashboards, navigation systems and entertainment systems; In medical devices, they are used in portable or wearable devices that require highly accurate signal transmission; In addition, FFC/FPC is also widely used in industrial automation, aerospace, military equipment, test and measurement equipment and computer peripherals, etc. These applications have strict requirements for the size, weight and signal quality of connectors.

0520443345 Datasheet

0520443345 Datasheet , 52044,-40°C ~ 85°C,Through Hole, Right Angle,Kinked Pin,Phosphor Bronze,Tin,FFC, FPC,Contacts, Top,33,0.049" (1.25mm),0.30mm,0.197" (5.00mm),Straight,Polybutylene Terephthalate (PBT), Polyester,200V,UL94 V-0

0520443345 Classification

FFC, FPC (Flat Flexible) Connectors

FFC, FPC (Flat Flexible) Connectors are high-density, lightweight electronic connection components designed specifically for precision electronic devices in confined spaces. This connector is composed of multiple layers of polyester film and embedded with copper foil conductive paths, which can achieve efficient transmission of electronic signals. FFC/FPC connectors adopt a flat ribbon structure, usually with connector interfaces at one or both ends, which can be easily connected to circuit boards or other electronic components. Its design principle is based on flexible circuit technology, which enables FFC/FPC to maintain signal stability and integrity in complex environments, while possessing good anti vibration and anti impact performance.
