What is 29-4010

Cinch Connectivity Solutions AIM-Cambridge Part Number 29-4010（Coaxial Connectors (RF)）, developed and manufactured by Cinch Connectivity Solutions AIM-Cambridge, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

29-4010 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

29-4010 Specifications

  • Part Number29-4010
  • CategoryCoaxial Connectors (RF)
  • ManufacturerCinch Connectivity Solutions AIM-Cambridge
  • DescriptionCONN MINI UHF PLUG STR CRIMP
  • Package-
  • Series-
  • Mounting TypeFree Hanging (In-Line)
  • Frequency - Max2GHz
  • ImpedanceNon-Constant
  • Connector TypePlug, Male Pin
  • Contact TerminationCrimp or Solder
  • Connector StyleUHF, Mini
  • Fastening TypeThreaded
  • Housing ColorSilver
  • Shield TerminationCrimp
  • Number of Ports1
  • Cable GroupRG-58

Application of 29-4010

Coaxial Connectors (RF) have become standard components in wireless communications, radio, television, radar, satellite communications and many other fields due to their excellent performance and a wide range of application scenarios. In the field of wireless communication, coaxial connectors are widely used in the connection of base stations, antennas, RF front ends and other equipment to ensure efficient transmission of signals in complex environments. In the field of broadcast television, it is used to connect transmitters, antennas and other equipment to ensure the clarity and stability of the signal. The field of radar and satellite communication is also inseparable from the support of coaxial connectors, which play an important role in high frequency and long distance signal transmission.

29-4010 Datasheet

29-4010 Datasheet , Free Hanging (In-Line),2GHz,Non-Constant,Plug, Male Pin,Crimp or Solder,UHF, Mini,Threaded,Silver,Crimp,1,RG-58

29-4010 Classification

Coaxial Connectors (RF)

Coaxial Connectors (RF), the radio frequency coaxial connector, is a professional connector for transmitting radio frequency signals. This type of connector is usually used in radio communications, radar systems, satellite communications, and radio and television. Coaxial connectors are designed with electrical performance and mechanical stability in mind to ensure low loss and high fidelity of RF signals during transmission.
