What is 302R29W681KV3E-****-SC

Johanson Dielectrics Inc. Part Number 302R29W681KV3E-****-SC（Ceramic Capacitors）, developed and manufactured by Johanson Dielectrics Inc., distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

302R29W681KV3E-****-SC is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

302R29W681KV3E-****-SC Specifications

  • Part Number302R29W681KV3E-****-SC
  • CategoryCeramic Capacitors
  • ManufacturerJohanson Dielectrics Inc.
  • DescriptionCAP CER 680PF 250VAC X7R 1808
  • PackageCut Tape (CT)
  • SeriesSC
  • Features-
  • Operating Temperature-55°C ~ 125°C
  • Mounting TypeSurface Mount, MLCC
  • Package / Case1808 (4520 Metric)
  • ApplicationsSafety
  • Tolerance±10%
  • Temperature CoefficientX7R
  • Size / Dimension0.189" L x 0.080" W (4.80mm x 2.03mm)
  • Voltage - Rated250V
  • Lead Spacing-
  • Thickness (Max)0.085\" (2.16mm)
  • RatingsX2
  • Height - Seated (Max)-
  • Capacitance680 pF
  • Lead Style-
  • Failure Rate-

Application of 302R29W681KV3E-****-SC

Ceramic capacitors are widely used in various electronic devices and communication systems, especially where stable capacitance values and high frequency response are required. They are used for filtering, coupling, and bypass to ensure signal purity and stable system operation. In the field of computer science, ceramic capacitors play a crucial role in power supply filtering and smoothing voltage fluctuations. In addition, it is commonly used in engine control units, airbag trigger systems, and automotive entertainment systems in automotive electronics systems for precise timing control and signal processing. Medical devices such as electrocardiograph and ultrasonic diagnostic equipment also rely on ceramic capacitors to ensure circuit reliability and measurement accuracy.

302R29W681KV3E-****-SC Datasheet

302R29W681KV3E-****-SC Datasheet , Cut Tape (CT),SC,-55°C ~ 125°C,Surface Mount, MLCC,1808 (4520 Metric),Safety,±10%,X7R,0.189" L x 0.080" W (4.80mm x 2.03mm),250V,0.085\" (2.16mm),X2,680 pF

302R29W681KV3E-****-SC Classification

Ceramic Capacitors

Ceramic capacitors, also known as ceramic dielectric capacitors or single stone capacitors, are capacitors that use ceramic materials as the dielectric. Its core components include two metal electrodes and a ceramic dielectric layer sandwiched in the middle. This design principle enables ceramic capacitors to have high stability, low loss, wide temperature range, and high frequency response characteristics. Ceramic capacitors can be classified into various types based on the different dielectric materials, including low temperature coefficient (NP0/C0G), high temperature coefficient (X7R/X5R), and high dielectric constant (Z5U/Y5V).

FAQ about Ceramic Capacitors

  • 1. What are ceramic capacitors used for?

    Ceramic capacitors are widely used in various electronic devices, mainly for:

    Coupling and decoupling: used in circuits to isolate DC signals while transmitting AC signals.
    Filtering: remove noise from the power supply or smooth the output voltage.
    Resonant circuit: such as oscillators in radio frequency (RF) circuits.
    Temperature compensation: some types of ceramic capacitors have temperature coefficients that can be used to stabilize circuit performance.
    Bypass: provide a low impedance path for high-frequency signals, thereby reducing the impact on other parts.

  • 2. Can I replace film capacitors with ceramic capacitors?

    In many cases, ceramic capacitors can be used to replace film capacitors, especially when smaller size and lower cost are required. However, it is important to note that ceramic capacitors may have different temperature coefficients and self-healing characteristics, which may affect performance in a specific application.

  • 3. Can I replace ceramic capacitors with film capacitors?

    Film capacitors can be used to replace ceramic capacitors in some application scenarios, especially when better temperature stability and lower losses are required.
