Schurter Inc. 6173.002
The picture is for reference only, please refer to the product specification
- 6173.002
- Schurter Inc.
- PWR ENT RCPT IEC320-C22 PANEL QC
- Power Entry Connectors - Inlets, Outlets, Modules
- 6173.002 Datasheet
- -
- -
-
Lead free / RoHS Compliant - 3550
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is 6173.002
Schurter Inc. Part Number 6173.002（Power Entry Connectors - Inlets, Outlets, Modules）, developed and manufactured by Schurter Inc., distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
6173.002 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
6173.002 Specifications
- Part Number6173.002
- CategoryPower Entry Connectors - Inlets, Outlets, Modules
- ManufacturerSchurter Inc.
- DescriptionPWR ENT RCPT IEC320-C22 PANEL QC
- Package-
- Series1681
- Mounting TypePanel Mount, Snap-In
- TerminationQuick Connect - 0.250" (6.3mm)
- Ingress ProtectionIP20
- ApprovalscULus, ENEC
- Number of Positions3
- Connector TypeReceptacle, Male Blades
- Connector StyleIEC 320-C22
- Material Flammability RatingUL94 V-0
- Filter TypeUnfiltered - Commercial
- Current - IEC16A
- Voltage - IEC250VAC
- Current - UL20A
- Voltage - UL250VAC
- FuseNo
- Panel Cutout DimensionsRectangular - 33.10mm x 25.10mm
- Panel Thickness0.059" (1.50mm)
