684M21W1103L461

NorComp Inc. 684M21W1103L461

The picture is for reference only, please refer to the product specification

  • 684M21W1103L461
  • NorComp Inc.
  • CONN D-SUB PLUG 21POS R/A SOLDER
  • D-Sub Connectors
  • 684M21W1103L461 Datasheet
  • -
  • -
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 4348
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is 684M21W1103L461

NorComp Inc. Part Number 684M21W1103L461（D-Sub Connectors）, developed and manufactured by NorComp Inc., distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

684M21W1103L461 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

684M21W1103L461 Specifications

  • Part Number684M21W1103L461
  • CategoryD-Sub Connectors
  • ManufacturerNorComp Inc.
  • DescriptionCONN D-SUB PLUG 21POS R/A SOLDER
  • Package-
  • Series684M
  • FeaturesBoard Lock, Grounding Indents, Mounting Brackets
  • Mounting TypeBoard Edge, Through Hole, Right Angle
  • TerminationSolder
  • Current Rating5A, 40A
  • Contact FinishGold
  • Number of Positions21 (20 + 1 Power)
  • Connector TypePlug, Male Pins
  • Contact Finish ThicknessFlash
  • Number of Rows2
  • Connector StyleD-Sub, Combo
  • Contact TypeSignal and Power
  • Flange FeatureHousing/Shell (4-40)
  • Shell Material, FinishSteel, Nickel Plated
  • Material Flammability RatingUL94 V-0
  • Shell Size, Connector Layout3 (DB, B) - 21W1

Application of 684M21W1103L461

D-Sub Connectors play an important role in many fields such as computers and peripherals, communications and networking, industrial automation, and audio and video. These connectors are often used to realize the exchange of signals and data between devices, for example, in computer peripherals, they are used to connect computer peripherals such as keyboards, mice, printers, etc. In communication devices such as network switching devices, modems, routers, etc., D-Sub connectors are used to transmit data and signals. In industrial automation, they are used to connect PLCS (programmable logic controllers) and other control systems. In addition, the D-Sub connector is also an indispensable component in test and measurement equipment for data acquisition and transmission, as well as the interconnection of in-car networks in automotive electronics.

684M21W1103L461 Datasheet

684M21W1103L461 Datasheet , 684M,Board Lock, Grounding Indents, Mounting Brackets,Board Edge, Through Hole, Right Angle,Solder,5A, 40A,Gold,21 (20 + 1 Power),Plug, Male Pins,Flash,2,D-Sub, Combo,Signal and Power,Housing/Shell

684M21W1103L461 Classification

D-Sub Connectors

D-Sub Connectors are widely used electronic connectors whose design is characterized by their unique D-shaped metal housing, a shape that not only provides mechanical support but also ensures the correct orientation and alignment of the connector, preventing misinsertion. The D-Sub connector consists of a series of parallel pins or hole pins that are embedded into a D-shaped housing that itself provides protection for the contacts, but also acts as a grounding path and as part of electromagnetic interference (EMI) and radio frequency (RF) shielding. The design principle of the D-Sub connector is based on the physical contact of the metal contact point, and the corresponding interface is connected through the spring-loaded metal contact to form a stable electrical connection. Its features include high reliability, ease of plugging, and a wide range of pin configuration options for varying density signal transmission needs.
