What is 8-1393480-5

TE Connectivity AMP Connectors Part Number 8-1393480-5（D-Sub Connectors）, developed and manufactured by TE Connectivity AMP Connectors, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

8-1393480-5 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

8-1393480-5 Specifications

  • Part Number8-1393480-5
  • CategoryD-Sub Connectors
  • ManufacturerTE Connectivity AMP Connectors
  • DescriptionCONN D-SUB PLUG 9POS R/A SOLDER
  • Package-
  • SeriesAMPLIMITE HD-20
  • FeaturesBoard Lock, Ground Strap, Grounding Indents
  • Mounting TypeThrough Hole, Right Angle
  • TerminationSolder
  • Current Rating2.2A
  • Contact FinishGold
  • Number of Positions9
  • Connector TypePlug, Male Pins
  • Contact Finish Thickness30µin (0.76µm)
  • Number of Rows2
  • Connector StyleD-Sub
  • Contact TypeSignal
  • Flange FeatureHousing/Shell (4-40)
  • Shell Material, FinishSteel, Tin Plated
  • Material Flammability RatingUL94 V-0
  • Shell Size, Connector Layout1 (DE, E)

Application of 8-1393480-5

D-Sub Connectors play an important role in many fields such as computers and peripherals, communications and networking, industrial automation, and audio and video. These connectors are often used to realize the exchange of signals and data between devices, for example, in computer peripherals, they are used to connect computer peripherals such as keyboards, mice, printers, etc. In communication devices such as network switching devices, modems, routers, etc., D-Sub connectors are used to transmit data and signals. In industrial automation, they are used to connect PLCS (programmable logic controllers) and other control systems. In addition, the D-Sub connector is also an indispensable component in test and measurement equipment for data acquisition and transmission, as well as the interconnection of in-car networks in automotive electronics.

8-1393480-5 Datasheet

8-1393480-5 Datasheet , AMPLIMITE HD-20,Board Lock, Ground Strap, Grounding Indents,Through Hole, Right Angle,Solder,2.2A,Gold,9,Plug, Male Pins,30µin (0.76µm),2,D-Sub,Signal,Housing/Shell (4-40),Steel, Tin Plated,UL94 V-0,1 (DE

8-1393480-5 Classification

D-Sub Connectors

D-Sub Connectors are widely used electronic connectors whose design is characterized by their unique D-shaped metal housing, a shape that not only provides mechanical support but also ensures the correct orientation and alignment of the connector, preventing misinsertion. The D-Sub connector consists of a series of parallel pins or hole pins that are embedded into a D-shaped housing that itself provides protection for the contacts, but also acts as a grounding path and as part of electromagnetic interference (EMI) and radio frequency (RF) shielding. The design principle of the D-Sub connector is based on the physical contact of the metal contact point, and the corresponding interface is connected through the spring-loaded metal contact to form a stable electrical connection. Its features include high reliability, ease of plugging, and a wide range of pin configuration options for varying density signal transmission needs.
