National Semiconductor ADC102S021CIMM/NOPB
The picture is for reference only, please refer to the product specification
- ADC102S021CIMM/NOPB
- National Semiconductor
- IC ADC 10BIT SAR 8VSSOP
- Data Acquisition - Analog to Digital Converters (ADC)
- ADC102S021CIMM/NOPB Datasheet
- 8-TSSOP, 8-MSOP (0.118\", 3.00mm Width)
- Bulk
-
Lead free / RoHS Compliant - 2666
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is ADC102S021CIMM/NOPB
National Semiconductor Part Number ADC102S021CIMM/NOPB（Data Acquisition - Analog to Digital Converters (ADC)）, developed and manufactured by National Semiconductor, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
ADC102S021CIMM/NOPB is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
ADC102S021CIMM/NOPB Specifications
- Part NumberADC102S021CIMM/NOPB
- CategoryData Acquisition - Analog to Digital Converters (ADC)
- ManufacturerNational Semiconductor
- DescriptionIC ADC 10BIT SAR 8VSSOP
- PackageBulk
- Series-
- Features-
- Operating Temperature-40°C ~ 85°C
- Mounting TypeSurface Mount
- Package / Case8-TSSOP, 8-MSOP (0.118\", 3.00mm Width)
- Supplier Device Package8-VSSOP
- Reference TypeSupply
- Sampling Rate (Per Second)200k
- Data InterfaceSPI, DSP
- Number of Bits10
- Voltage - Supply, Analog2.7V ~ 5.25V
- Voltage - Supply, Digital2.7V ~ 5.25V
- Number of Inputs2
- Input TypeSingle Ended
- ConfigurationMUX-S/H-ADC
- Ratio - S/H:ADC1:1
- Number of A/D Converters1
- ArchitectureSAR
Application of ADC102S021CIMM/NOPB
ADC102S021CIMM/NOPB Datasheet
ADC102S021CIMM/NOPB Datasheet , Bulk,-40°C ~ 85°C,Surface Mount,8-TSSOP, 8-MSOP (0.118\", 3.00mm Width),8-VSSOP,Supply,200k,SPI, DSP,10,2.7V ~ 5.25V,2.7V ~ 5.25V,2,Single Ended,MUX-S/H-ADC,1:1,1,SAR
ADC102S021CIMM/NOPB Classification
Data Acquisition - Analog to Digital Converters (ADC)
FAQ about Data Acquisition - Analog to Digital Converters (ADC)
-
1. How does ADC convert analog to digital?
The technology that converts analog sound signals into digital signals is called analog-to-digital conversion technology (Analog to Digital Converter, referred to as ADC). The function of ADC is to convert continuously changing analog signals into discrete digital signals. The process of analog-to-digital conversion can be completed by steps such as sampling, holding, quantization, and encoding.
-
2. How many types of ADC are there?
The types of ADC (Analog-to-Digital Converter) mainly include:
1. Integral ADC: Its working principle is to convert the input voltage into time (pulse width signal) or frequency (pulse frequency), and then obtain the digital value by the timer/counter. The advantage of the integral ADC is that it can obtain high resolution with a simple circuit and has strong anti-interference ability, but the disadvantage is that the conversion rate is extremely low because the conversion accuracy depends on the integration time.
2. Successive approximation type (SAR ADC): The successive approximation ADC is one of the most common architectures. Its basic principle is to convert by gradually approximating the value of the analog input signal. The advantages of the successive approximation ADC are high speed and low power consumption. It is cheap at low resolution, but expensive at high precision.
3. Parallel comparison type/serial-parallel comparison type ADC: The parallel comparison type AD uses m -
3. What process converts analog to digital?
There are three basic processes for analog to digital conversion:
The first process is "sampling", which is to extract the sample value of the analog signal at equal intervals to turn the continuous signal into a discrete signal.
The second process is called "quantization", which is to convert the extracted sample value into the closest digital value to represent the size of the extracted sample value.
The third process is "encoding", which is to represent the quantized value with a set of binary digits. After these three processes, the digitization of the analog signal can be completed. This method is called "pulse encoding".
After the digital signal is transmitted to the receiving end, a restoration process is required, that is, the received digital signal is converted back to an analog signal so that it can be understood by the receiver. This process is called "digital-to-analog conversion", which reproduces it as sound or image.
