AYF333535

Panasonic Electric Works AYF333535

The picture is for reference only, please refer to the product specification

  • AYF333535
  • Panasonic Electric Works
  • CONN FPC 35POS 0.30MM R/A
  • FFC, FPC (Flat Flexible) Connectors
  • AYF333535 Datasheet
  • -
  • -
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 26557
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is AYF333535

Panasonic Electric Works Part Number AYF333535（FFC, FPC (Flat Flexible) Connectors）, developed and manufactured by Panasonic Electric Works, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

AYF333535 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

AYF333535 Specifications

  • Part NumberAYF333535
  • CategoryFFC, FPC (Flat Flexible) Connectors
  • ManufacturerPanasonic Electric Works
  • DescriptionCONN FPC 35POS 0.30MM R/A
  • Package-
  • SeriesY3B
  • Operating Temperature-55°C ~ 85°C
  • Mounting TypeSurface Mount, Right Angle
  • TerminationSolder
  • Contact MaterialCopper Alloy
  • Contact FinishGold
  • Flat Flex TypeFPC
  • Connector/Contact TypeContacts, Top and Bottom
  • Number of Positions35
  • Pitch0.012" (0.30mm)
  • FFC, FCB Thickness0.20mm
  • Height Above Board0.036" (0.90mm)
  • Locking FeatureFlip Lock, Backlock
  • Cable End TypeTapered
  • Housing MaterialLiquid Crystal Polymer (LCP)
  • Voltage Rating50V
  • Material Flammability RatingUL94 V-0
  • Actuator MaterialLiquid Crystal Polymer (LCP)

Application of AYF333535

FFC, FPC (Flat Flexible) Connectors) play an important role in several high-tech industries and applications due to their unique physical properties and high reliability. They are commonly found in consumer electronics, such as smartphones and tablets, to connect screens, cameras and other internal components; In the field of automotive electronics, FFC/FPC connectors are used for line connection of dashboards, navigation systems and entertainment systems; In medical devices, they are used in portable or wearable devices that require highly accurate signal transmission; In addition, FFC/FPC is also widely used in industrial automation, aerospace, military equipment, test and measurement equipment and computer peripherals, etc. These applications have strict requirements for the size, weight and signal quality of connectors.

AYF333535 Datasheet

AYF333535 Datasheet , Y3B,-55°C ~ 85°C,Surface Mount, Right Angle,Solder,Copper Alloy,Gold,FPC,Contacts, Top and Bottom,35,0.012" (0.30mm),0.20mm,0.036" (0.90mm),Flip Lock, Backlock,Tapered,Liquid Crystal Polymer (LCP),50V,UL94

AYF333535 Classification

FFC, FPC (Flat Flexible) Connectors

FFC, FPC (Flat Flexible) Connectors are high-density, lightweight electronic connection components designed specifically for precision electronic devices in confined spaces. This connector is composed of multiple layers of polyester film and embedded with copper foil conductive paths, which can achieve efficient transmission of electronic signals. FFC/FPC connectors adopt a flat ribbon structure, usually with connector interfaces at one or both ends, which can be easily connected to circuit boards or other electronic components. Its design principle is based on flexible circuit technology, which enables FFC/FPC to maintain signal stability and integrity in complex environments, while possessing good anti vibration and anti impact performance.
