Cinch Connectivity Solutions Trompeter BJ50
The picture is for reference only, please refer to the product specification
- BJ50
- Cinch Connectivity Solutions Trompeter
- CONN TPS JACK STR 50 OHM SOLDER
- Coaxial Connectors (RF)
- BJ50 Datasheet
- -
- -
-
Lead free / RoHS Compliant - 5137
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is BJ50
Cinch Connectivity Solutions Trompeter Part Number BJ50（Coaxial Connectors (RF)）, developed and manufactured by Cinch Connectivity Solutions Trompeter, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
BJ50 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
BJ50 Specifications
- Part NumberBJ50
- CategoryCoaxial Connectors (RF)
- ManufacturerCinch Connectivity Solutions Trompeter
- DescriptionCONN TPS JACK STR 50 OHM SOLDER
- Package-
- Series50
- FeaturesThree Lug
- Mounting TypePanel Mount
- Frequency - Max500MHz
- Impedance50 Ohm
- Mounting FeatureBulkhead - Rear Side Nut
- Connector TypeJack, Female Socket
- Contact TerminationSolder Cup
- Connector StyleTPS
- Fastening TypeBayonet Lock
- Housing ColorSilver
- Shield TerminationSolder
- Number of Ports1
Application of BJ50
BJ50 Datasheet
BJ50 Datasheet , 50,Three Lug,Panel Mount,500MHz,50 Ohm,Bulkhead - Rear Side Nut,Jack, Female Socket,Solder Cup,TPS,Bayonet Lock,Silver,Solder,1
BJ50 Classification
Coaxial Connectors (RF)
FAQ about Coaxial Connectors (RF)
-
1. What is the difference between RF connectors and coaxial connectors?
Structure and performance indicators
There are significant differences between RF connectors and coaxial connectors in structure, application scenarios and performance indicators.
Structural differences
Coaxial connector: Coaxial connector consists of inner conductor, insulation layer, outer conductor and sheath. The inner conductor is used to connect the signal line, and the outer conductor not only serves as the ground wire of the signal line, but also acts as a shield against electromagnetic fields to prevent signal interference.
RF connector: RF connector usually refers to RF coaxial connector, which is similar in structure to coaxial connector, but RF connector focuses more on the transmission of high-frequency signals, so it has higher requirements in material selection and manufacturing process. .
Differences in performance metrics
Characteristic impedance: Characteristic impedance is an important indicator of RF coaxial connectors, which determines the impedance type of the cable connected to it. The characteristic impedance is determined by the inner diameter of the outer conductor, the outer diameter of the inner conductor, and the dielectric constant of the medium between the inner and outer conductors.
Voltage standing wave ratio: The voltage standing wave ratio reflects the matching level of the connector and is an important parameter to measure the performance of the connector.
To sum up, coaxial connector focuses more on general signal transmission, while RF connector focuses on optimized transmission of high-frequency signals. Both have different emphasis on structure, application scenarios and performance indicators.
-
2. What is coaxial cable in electrical?
Coaxial cable is a transmission medium consisting of an inner conductor, an insulation layer, an outer conductor and a sheath. The inner conductor is usually one or more copper wires, and the outer conductor is composed of a metal braid or metal foil, both located on the same axis. This structure enables coaxial cables to have lower losses and higher anti-interference capabilities when transmitting high-frequency signals.
Coaxial cable structure and characteristics
The structure of coaxial cable includes the following parts:
Inner conductor: usually consists of a single or multiple copper wires.
Insulating layer: Located outside the inner conductor, it acts as an isolation and dielectric.
Outer conductor: usually constructed of metal braid or metal foil to form a shield.
Jacket: The outer layer that protects a cable, usually made of PVC or Teflon material. -
3. What is a coaxial plug used for?
The main uses of coaxial plugs include the following aspects:
Signal transmission: Coaxial plugs are used to connect both ends of coaxial cables to ensure that electrical signals can be transmitted stably between cables. It provides a stable and reliable connection, ensuring that signals can be transmitted efficiently from one device to another.
Shielding protection: When connecting to a coaxial cable, the coaxial plug can provide good shielding protection to prevent interference from external interference signals. This can reduce signal attenuation and distortion and improve the quality and reliability of signal transmission.
Connecting devices: Coaxial plugs can connect different types of devices such as televisions, modems, antennas, etc. It provides a standardized interface that enables various devices to connect and communicate easily.
Maintenance and replacement: Coaxial plugs are easy to install and replace, making maintenance and replacement of coaxial cables simple and convenient. When a coaxial cable needs to be replaced or repaired, only the connector needs to be replaced rather than the entire cable.
Application in avionics equipment: Coaxial plugs play an important role in avionics equipment and are used to connect various sensors, controllers, displays, computers and other equipment to achieve signal transmission and electrical connection between equipment. It can provide stable signal transmission and good anti-interference performance to ensure the normal operation of the equipment.
Application in communication systems: In aviation communication systems, coaxial plugs are used to connect antennas and transceivers to realize the transmission and reception of wireless signals. It can provide high-frequency transmission capabilities and good signal quality to ensure stable and reliable communication.
