BZT52C3V3-TP

Micro Commercial Co BZT52C3V3-TP

The picture is for reference only, please refer to the product specification

  • BZT52C3V3-TP
  • Micro Commercial Co
  • DIODE ZENER 3.3V 500MW SOD123
  • Diodes - Zener - Single
  • BZT52C3V3-TP Datasheet
  • SOD-123
  • Tape & Reel (TR)
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 21779
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is BZT52C3V3-TP

Micro Commercial Co Part Number BZT52C3V3-TP（Diodes - Zener - Single）, developed and manufactured by Micro Commercial Co, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

BZT52C3V3-TP is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

BZT52C3V3-TP Specifications

  • Part NumberBZT52C3V3-TP
  • CategoryDiodes - Zener - Single
  • ManufacturerMicro Commercial Co
  • DescriptionDIODE ZENER 3.3V 500MW SOD123
  • PackageTape & Reel (TR)
  • Series-
  • Operating Temperature-65°C ~ 150°C
  • Mounting TypeSurface Mount
  • Package / CaseSOD-123
  • Supplier Device PackageSOD-123
  • Tolerance±6%
  • Power - Max500 mW
  • Voltage - Forward (Vf) (Max) @ If900 mV @ 10 mA
  • Current - Reverse Leakage @ Vr5 µA @ 1 V
  • Voltage - Zener (Nom) (Vz)3.3 V
  • Impedance (Max) (Zzt)95 Ohms

Application of BZT52C3V3-TP

Zener-Single has a wide range of applications in several electronic engineering fields. In power supply design, it is often used to build a simple voltage regulator circuit to provide a stable power supply voltage for sensitive components such as microprocessors and sensors. In communication systems, especially where the signal level needs to be precisely controlled, such as digital logic circuits, RF front ends, etc., Zener-single can effectively prevent signal distortion caused by voltage fluctuations. In addition, the application of Zener diodes as overvoltage protection components in automotive electronics, industrial control and consumer electronics products also reflects the importance of Zener-single in protecting circuits from unexpected voltage shocks.

BZT52C3V3-TP Datasheet

BZT52C3V3-TP Datasheet , Tape & Reel (TR),-65°C ~ 150°C,Surface Mount,SOD-123,SOD-123,±6%,500 mW,900 mV @ 10 mA,5 µA @ 1 V,3.3 V,95 Ohms

BZT52C3V3-TP Classification

Diodes - Zener - Single

Zener-single refers to a circuit design that focuses on stabilizing the voltage at a particular node in the circuit by carefully configuring a Zener diode as a voltage reference or protection element, and the design focuses on dealing with voltage fluctuations in a Single direction (forward or reverse, depending on the application). Zener diode with its unique reverse breakdown characteristic, after reaching a specific reverse voltage, the current increases significantly while the voltage remains almost unchanged, this characteristic is cleverly used in Zener-single design to achieve voltage stability or overload protection of the circuit.

FAQ about Diodes - Zener - Single

  • 1. What are the two types of Zener diodes?

    Zener diodes are mainly divided into two types: one that works based on the avalanche effect (usually in high voltage applications) and the other that works based on the Zener breakdown mechanism (suitable for lower voltages).

  • 2. What is the difference between a Zener diode and a Schottky diode?

    Schottky diodes have a low forward voltage drop and fast switching speed, making them suitable for high-frequency applications. In contrast, Zener diodes are mainly used for voltage regulation and voltage stabilization.

  • 3. Is every diode a Zener diode?

    No. Although all Zener diodes are a type of diode, not all diodes can be called Zener diodes.
