What is C22F.0005
Schurter Inc. Part Number C22F.0005（Power Entry Connectors - Inlets, Outlets, Modules）, developed and manufactured by Schurter Inc., distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
C22F.0005 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
C22F.0005 Specifications
- Part NumberC22F.0005
- CategoryPower Entry Connectors - Inlets, Outlets, Modules
- ManufacturerSchurter Inc.
- DescriptionPWR ENT RCPT IEC320-C22 PNL SLDR
- Package-
- SeriesC22F
- FeaturesShielded
- Mounting TypePanel Mount, Flange
- TerminationSolder Eyelet
- Ingress ProtectionIP40
- ApprovalscULus, ENEC
- Number of Positions3
- Connector TypeReceptacle, Male Blades
- Connector StyleIEC 320-C22
- Material Flammability RatingUL94 V-0
- Current - IEC16A
- Voltage - IEC250VAC
- Current - UL20A
- Voltage - UL250VAC
- FuseNo
