Aries Electronics C8118-04
The picture is for reference only, please refer to the product specification
- C8118-04
- Aries Electronics
- CONN IC DIP SOCKET 18POS TIN
- Sockets for ICs, Transistors
- C8118-04 Datasheet
- -
- -
-
Lead free / RoHS Compliant - 19389
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is C8118-04
Aries Electronics Part Number C8118-04（Sockets for ICs, Transistors）, developed and manufactured by Aries Electronics, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
C8118-04 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
C8118-04 Specifications
- Part NumberC8118-04
- CategorySockets for ICs, Transistors
- ManufacturerAries Electronics
- DescriptionCONN IC DIP SOCKET 18POS TIN
- Package-
- SeriesEdge-Grip?, C81
- TypeDIP, 0.3" (7.62mm) Row Spacing
- FeaturesClosed Frame
- Operating Temperature-55°C ~ 105°C
- Mounting TypeThrough Hole
- TerminationWire Wrap
- Housing MaterialPolyamide (PA46), Nylon 4/6, Glass Filled
- Pitch - Mating0.100" (2.54mm)
- Contact Finish - MatingTin
- Contact Finish - PostTin
- Contact Finish Thickness - Mating200µin (5.08µm)
- Number of Positions or Pins (Grid)18 (2 x 9)
- Contact Material - MatingPhosphor Bronze
- Pitch - Post0.100" (2.54mm)
- Contact Finish Thickness - Post200µin (5.08µm)
- Contact Material - PostPhosphor Bronze
Application of C8118-04
C8118-04 Datasheet
C8118-04 Datasheet , Edge-Grip?, C81,DIP, 0.3" (7.62mm) Row Spacing,Closed Frame,-55°C ~ 105°C,Through Hole,Wire Wrap,Polyamide (PA46), Nylon 4/6, Glass Filled,0.100" (2.54mm),Tin,Tin,200µin (5.08µm),18 (2 x 9),Phosphor
