What is DBV17W2S700G30LF

Amphenol ICC (FCI) Part Number DBV17W2S700G30LF（D-Sub Connectors）, developed and manufactured by Amphenol ICC (FCI), distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

DBV17W2S700G30LF is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

DBV17W2S700G30LF Specifications

Part NumberDBV17W2S700G30LF
CategoryD-Sub Connectors
ManufacturerAmphenol ICC (FCI)
DescriptionCONN D-SUB RCPT 17POS R/A SOLDER
Package-
SeriesDW
FeaturesBoard Lock, Mounting Brackets
Mounting TypeThrough Hole, Right Angle
TerminationSolder
Current Rating7.5A, 30A
Contact FinishGold
Number of Positions17 (15 + 2 Power)
Connector TypeReceptacle, Female Sockets
Number of Rows2
Connector StyleD-Sub, Combo
Contact TypeSignal and Power
Flange FeatureMating Side, Female Screwlock (4-40)
Shell Material, FinishSteel, Tin Plated
Material Flammability RatingUL94 V-0
Shell Size, Connector Layout3 (DB, B) - 17W2

Application of DBV17W2S700G30LF

D-Sub Connectors play an important role in many fields such as computers and peripherals, communications and networking, industrial automation, and audio and video. These connectors are often used to realize the exchange of signals and data between devices, for example, in computer peripherals, they are used to connect computer peripherals such as keyboards, mice, printers, etc. In communication devices such as network switching devices, modems, routers, etc., D-Sub connectors are used to transmit data and signals. In industrial automation, they are used to connect PLCS (programmable logic controllers) and other control systems. In addition, the D-Sub connector is also an indispensable component in test and measurement equipment for data acquisition and transmission, as well as the interconnection of in-car networks in automotive electronics.

DBV17W2S700G30LF Datasheet

DBV17W2S700G30LF Datasheet , DW,Board Lock, Mounting Brackets,Through Hole, Right Angle,Solder,7.5A, 30A,Gold,17 (15 + 2 Power),Receptacle, Female Sockets,2,D-Sub, Combo,Signal and Power,Mating Side, Female Screwlock (4-40),Steel, Tin

DBV17W2S700G30LF Classification

D-Sub Connectors

D-Sub Connectors are widely used electronic connectors whose design is characterized by their unique D-shaped metal housing, a shape that not only provides mechanical support but also ensures the correct orientation and alignment of the connector, preventing misinsertion. The D-Sub connector consists of a series of parallel pins or hole pins that are embedded into a D-shaped housing that itself provides protection for the contacts, but also acts as a grounding path and as part of electromagnetic interference (EMI) and radio frequency (RF) shielding. The design principle of the D-Sub connector is based on the physical contact of the metal contact point, and the corresponding interface is connected through the spring-loaded metal contact to form a stable electrical connection. Its features include high reliability, ease of plugging, and a wide range of pin configuration options for varying density signal transmission needs.

FAQ about D-Sub Connectors

1. What is a D-SUB connector

The name of the D-SUB connector comes from the D-shaped appearance of its plug. It is a double-row cable connector widely used in computer, industrial automation and communication fields. This connector consists of two parts: a plug and a socket. It is connected through pinholes and pins. It can transmit video, audio and digital signals and provide a large number of grounding points.
The D-SUB connector is a compact and versatile connector mainly used to support power, analog, RF or digital signal transmission. It has a variety of models, options and accessories and is a very economical interconnection solution.
2. Classification of D-SUB connectors

‌Solder cup D-Sub connector‌: This connector meets commercial industrial standards and can be paired with any docking solder cup D-Sub connector. The contacts are electroplated with flash gold, and the connector insulator meets the UL94V-0 standard. The maximum wire size is 20 AWG, and 9, 25, 37 and 50 pin specifications are available.

‌Crimp D-Sub connector‌: Crimp D-Sub connectors meet commercial industrial standards and can be used for most standard D-Sub male connectors. Compatible with 20-28 AWG wire range, available in 9, 15, 25 and 50 pin sizes.

‌Punch-type D-Sub connector‌: This connector is easily soldered into the through-hole of the printed circuit board or used in many other applications. Solder placement follows a standard footprint, and gold-plated contacts ensure long life. As an industrial standard commercial DB37 female PCB type connector, it has standard mounting holes for application flexibility.
3. Specifications and models of D-SUB connectors

There are many specifications and models of D-SUB connectors, and the common ones are D-SUB 9-pin, D-SUB 15-pin, D-SUB 25-pin and other series. These series have their own scope of application and characteristics. Users can choose the appropriate specifications and models according to actual needs. At the same time, the prices of different specifications and models are also different. Users need to consider factors such as cost and applicability when choosing.
4. ‌D-SUB connector insulation is poor

Performance: short circuit, insulation resistance is too poor.

Cause: high humidity in the use environment, serious pollution, water or other liquids penetrate into the insulator, etc.
Solution: Improve the use environment, clean the inside of the insulator, and replace the insulator.
