FA28NP02A182JNU06

TDK Corporation FA28NP02A182JNU06

The picture is for reference only, please refer to the product specification

  • FA28NP02A182JNU06
  • TDK Corporation
  • CAP CER 1800PF 100V NP0 RADIAL
  • Ceramic Capacitors
  • FA28NP02A182JNU06 Datasheet
  • Radial
  • Tape & Box (TB)
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 2757
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is FA28NP02A182JNU06

TDK Corporation Part Number FA28NP02A182JNU06（Ceramic Capacitors）, developed and manufactured by TDK Corporation, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

FA28NP02A182JNU06 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

FA28NP02A182JNU06 Specifications

  • Part NumberFA28NP02A182JNU06
  • CategoryCeramic Capacitors
  • ManufacturerTDK Corporation
  • DescriptionCAP CER 1800PF 100V NP0 RADIAL
  • PackageTape & Box (TB)
  • SeriesFA
  • FeaturesHigh Temperature
  • Operating Temperature-55°C ~ 150°C
  • Mounting TypeThrough Hole
  • Package / CaseRadial
  • ApplicationsAutomotive
  • Tolerance±5%
  • Temperature CoefficientC0G, NP0
  • Size / Dimension0.157" L x 0.098" W (4.00mm x 2.50mm)
  • Voltage - Rated100V
  • Lead Spacing0.197\" (5.00mm)
  • Thickness (Max)-
  • RatingsAEC-Q200
  • Height - Seated (Max)0.217\" (5.50mm)
  • Capacitance1800 pF
  • Lead StyleFormed Leads - Kinked
  • Failure Rate-

Application of FA28NP02A182JNU06

Ceramic capacitors are widely used in various electronic devices and communication systems, especially where stable capacitance values and high frequency response are required. They are used for filtering, coupling, and bypass to ensure signal purity and stable system operation. In the field of computer science, ceramic capacitors play a crucial role in power supply filtering and smoothing voltage fluctuations. In addition, it is commonly used in engine control units, airbag trigger systems, and automotive entertainment systems in automotive electronics systems for precise timing control and signal processing. Medical devices such as electrocardiograph and ultrasonic diagnostic equipment also rely on ceramic capacitors to ensure circuit reliability and measurement accuracy.

FA28NP02A182JNU06 Datasheet

FA28NP02A182JNU06 Datasheet , Tape & Box (TB),FA,High Temperature,-55°C ~ 150°C,Through Hole,Radial,Automotive,±5%,C0G, NP0,0.157" L x 0.098" W (4.00mm x 2.50mm),100V,0.197\" (5.00mm),AEC-Q200,0.217\" (5.50mm),1800 pF,Formed Leads -

FA28NP02A182JNU06 Classification

Ceramic Capacitors

Ceramic capacitors, also known as ceramic dielectric capacitors or single stone capacitors, are capacitors that use ceramic materials as the dielectric. Its core components include two metal electrodes and a ceramic dielectric layer sandwiched in the middle. This design principle enables ceramic capacitors to have high stability, low loss, wide temperature range, and high frequency response characteristics. Ceramic capacitors can be classified into various types based on the different dielectric materials, including low temperature coefficient (NP0/C0G), high temperature coefficient (X7R/X5R), and high dielectric constant (Z5U/Y5V).

FAQ about Ceramic Capacitors

  • 1. What is the difference between ceramic capacitors and electrolytic capacitors?

    Polarity: Ceramic capacitors are non-polar, while electrolytic capacitors are polar.
    Capacity range: Electrolytic capacitors generally offer larger capacitance values.
    Stability: Ceramic capacitors are more stable, especially when the temperature changes.
    Lifespan: Ceramic capacitors have a longer lifespan because there is no liquid electrolyte to dry out.

  • 2. Can ceramic capacitors be used for audio?

    Ceramic capacitors can be used in audio circuits, but care needs to be taken to select the right type to avoid introducing unnecessary noise or distortion.

  • 3. What is the difference between Class 1 and Class 2 ceramic capacitors?

    Class 1: has high accuracy and stable temperature coefficient, suitable for precision circuits.
    Class 2: has higher capacitance value, but larger temperature coefficient and tolerance, suitable for general applications.
