FDS6375

National Semiconductor FDS6375

The picture is for reference only, please refer to the product specification

  • FDS6375
  • National Semiconductor
  • SMALL SIGNAL FIELD-EFFECT TRANSI
  • Transistors - FETs, MOSFETs - Single
  • FDS6375 Datasheet
  • 8-SOIC (0.154\", 3.90mm Width)
  • Bulk
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 4315
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is FDS6375

National Semiconductor Part Number FDS6375（Transistors - FETs, MOSFETs - Single）, developed and manufactured by National Semiconductor, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

FDS6375 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

FDS6375 Specifications

  • Part NumberFDS6375
  • CategoryTransistors - FETs, MOSFETs - Single
  • ManufacturerNational Semiconductor
  • DescriptionSMALL SIGNAL FIELD-EFFECT TRANSI
  • PackageBulk
  • SeriesPowerTrench®
  • Operating Temperature-55°C ~ 175°C (TJ)
  • Mounting TypeSurface Mount
  • Package / Case8-SOIC (0.154\", 3.90mm Width)
  • Supplier Device Package8-SOIC
  • TechnologyMOSFET (Metal Oxide)
  • Power Dissipation (Max)2.5W (Ta)
  • FET TypeP-Channel
  • FET Feature-
  • Drain to Source Voltage (Vdss)20 V
  • Current - Continuous Drain (Id) @ 25°C8A (Ta)
  • Rds On (Max) @ Id, Vgs24mOhm @ 8A, 4.5V
  • Vgs(th) (Max) @ Id1.5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs36 nC @ 4.5 V
  • Input Capacitance (Ciss) (Max) @ Vds2.694 pF @ 10 V
  • Vgs (Max)±8V
  • Drive Voltage (Max Rds On, Min Rds On)2.5V, 4.5V

Application of FDS6375

FET and MOSFET-single (FETs, MOSFETs-Single) application field is extremely wide, almost covers the core part of all electronic devices. In the field of consumer electronics, from smartphones, tablets to wearable devices, FETs and MOSFETs are key components for signal processing and power management, ensuring the normal operation of devices and efficient energy consumption. In industrial control systems, they are widely used in the fields of motor drive, automated production lines and process control, improving production efficiency and system stability. In addition, in automotive electronics, medical equipment, aerospace and other high-tech fields, FET and MOSFET also play an irreplaceable role. In automotive electronics, for example, they are used in engine management systems, safety systems, and entertainment systems. In medical equipment, it is used for key links such as signal amplification and power control of precision instruments.

FDS6375 Datasheet

FDS6375 Datasheet , Bulk,PowerTrench®,-55°C ~ 175°C (TJ),Surface Mount,8-SOIC (0.154\", 3.90mm Width),8-SOIC,MOSFET (Metal Oxide),2.5W (Ta),P-Channel,20 V,8A (Ta),24mOhm @ 8A, 4.5V,1.5V @ 250µA,36 nC @ 4.5 V,2.694 pF @ 10

FDS6375 Classification

Transistors - FETs, MOSFETs - Single

FET (field effect transistor) is an electronic device that controls the flow of current in a semiconductor based on the electric field effect. It is mainly composed of three ends: Gate, Source and Drain, and the current between source and drain is modulated by changing the grid voltage.MOSFET (metal oxide semiconductor field effect transistor) is a special type of FET, which plays an important role in electronic design because of its high input impedance, low noise and low power consumption. Mosfet-single also refers to a single MOSFET element or a simple circuit unit with it as the core, which further improves performance stability and application range on the basis of retaining the basic characteristics of FET.

FAQ about Transistors - FETs, MOSFETs - Single

  • 1. How does a MOSFET work as an amplifier?

    A MOSFET can change the resistance between the source and drain by adjusting the gate voltage, which in turn affects the current flowing through this path. This allows the input signal to be amplified.

  • 2. Do MOSFETs work in AC or DC?

    MOSFETs can work in both DC and AC circuits, depending on the specific application requirements.

  • 3. How many watts per channel adcom mosfet 5300 amp？

    The Adcom GFA-5300 is a high-power stereo amplifier that uses MOSFET (Metal-Oxide-Semiconductor Field-Effect Transistor) technology. This amplifier is known for its robust power output and reliability.

    The Adcom GFA-5300 amplifier is rated to deliver 200 watts per channel into 8 ohms, and it can provide 300 watts per channel into 4 ohms. These specifications are typical for this model, but always check the specific documentation or manual that came with your unit to confirm the exact specifications, as there might be slight variations depending on the production run or any updates to the design.
