What is FF0115SA1E
JAE Electronics Part Number FF0115SA1E（FFC, FPC (Flat Flexible) Connectors）, developed and manufactured by JAE Electronics, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
FF0115SA1E is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
FF0115SA1E Specifications
- Part NumberFF0115SA1E
- CategoryFFC, FPC (Flat Flexible) Connectors
- ManufacturerJAE Electronics
- DescriptionCONN FPC BOTTOM 15POS 0.50MM R/A
- Package-
- SeriesFF01
- FeaturesSolder Retention
- Operating Temperature-40°C ~ 85°C
- Mounting TypeSurface Mount, Right Angle
- TerminationSolder
- Contact MaterialCopper Alloy
- Contact FinishGold
- Flat Flex TypeFPC
- Connector/Contact TypeContacts, Bottom
- Number of Positions15
- Pitch0.020" (0.50mm)
- FFC, FCB Thickness0.12mm
- Height Above Board0.036" (0.90mm)
- Locking FeatureFlip Lock
- Cable End TypeStraight
- Housing MaterialLiquid Crystal Polymer (LCP)
- Voltage Rating50V
- Material Flammability RatingUL94 V-0
- Actuator MaterialPolyphenylene Sulfide (PPS)
Application of FF0115SA1E
FF0115SA1E Datasheet
FF0115SA1E Datasheet , FF01,Solder Retention,-40°C ~ 85°C,Surface Mount, Right Angle,Solder,Copper Alloy,Gold,FPC,Contacts, Bottom,15,0.020" (0.50mm),0.12mm,0.036" (0.90mm),Flip Lock,Straight,Liquid Crystal Polymer (LCP),50V,UL94
FF0115SA1E Classification
FFC, FPC (Flat Flexible) Connectors
FAQ about FFC, FPC (Flat Flexible) Connectors
-
1. What is the difference between FFC and FPC connectors?
The main differences between FFC connectors and FPC connectors are in design, application, and performance.
Design Differences
FPC connectors: usually have a multi-layer structure and complex circuit design, are made of conductive materials, and are connected to circuit boards by welding, crimping, etc. FPC connectors are suitable for circuit boards of various shapes and sizes, have extremely high flexibility, and can adapt to different bending and twisting requirements.
FFC connectors: The structure is relatively simple, mainly composed of insulating materials and conductive materials, and are connected to cables by crimping or plugging. FFC connectors are usually used to connect components such as display screens, touch screens, and keyboards. Their flat design makes the cable more stable and reliable during the connection process. -
2. What is an FPC connector?
FPC connector (Flexible Printed Circuit Connector) is an electronic component designed for connecting flexible printed circuit boards (FPC). It has the characteristics of compact structure, light weight, and strong flexibility, and is widely used in electronic products with high space and weight requirements such as mobile phones, laptops, tablets, wearable devices, and camera modules.
The main features of FPC connectors include:
Miniaturization and high-density integration: can save space and simplify wiring procedures, thereby reducing labor costs.
Excellent flexibility: allows flexible twists and turns to adapt to various complex connection requirements.
Lightweight and low-cost: small size, light weight, easy installation, and strong durability. -
3. What is the difference between flexible PCB and FPC?
There are some differences between flexible PCB (FPC) and flexible circuit board (FPC) in definition and application scenarios.
Definition and materials
Flexible PCB (FPC): Flexible PCB is a type of flexible circuit board, usually made of flexible substrates such as polyimide (PI) or polyester film (PET). This material makes FPC have good flexibility and bendability, can move and stretch freely in three-dimensional space, and is suitable for electronic products that require high density, miniaturization and high reliability.
Flexible circuit board (FPC): Flexible circuit board is a printed circuit board made of polyimide or polyester film as the substrate, with high reliability and excellent flexibility. It has the characteristics of high wiring density, light weight, thin thickness, good bending, and can withstand millions of dynamic bending without damaging the wires.
