Hirose Electric Co Ltd FH12-22S-1SH
The picture is for reference only, please refer to the product specification
- FH12-22S-1SH
- Hirose Electric Co Ltd
- CONN FFC BOTTOM 22POS 1.00MM R/A
- FFC, FPC (Flat Flexible) Connectors
- FH12-22S-1SH Datasheet
- -
- -
-
Lead free / RoHS Compliant - 12940
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is FH12-22S-1SH
Hirose Electric Co Ltd Part Number FH12-22S-1SH（FFC, FPC (Flat Flexible) Connectors）, developed and manufactured by Hirose Electric Co Ltd, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
FH12-22S-1SH is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
FH12-22S-1SH Specifications
- Part NumberFH12-22S-1SH
- CategoryFFC, FPC (Flat Flexible) Connectors
- ManufacturerHirose Electric Co Ltd
- DescriptionCONN FFC BOTTOM 22POS 1.00MM R/A
- Package-
- SeriesFH12
- FeaturesSolder Retention, Zero Insertion Force (ZIF)
- Operating Temperature-40°C ~ 85°C
- Mounting TypeSurface Mount, Right Angle
- TerminationSolder
- Contact MaterialPhosphor Bronze
- Contact FinishTin-Lead
- Flat Flex TypeFFC, FPC
- Connector/Contact TypeContacts, Bottom
- Number of Positions22
- Pitch0.039" (1.00mm)
- FFC, FCB Thickness0.30mm
- Height Above Board0.079" (2.00mm)
- Locking FeatureFlip Lock
- Cable End TypeStraight
- Housing MaterialPolyamide (PA), Nylon
- Voltage Rating50V
- Material Flammability RatingUL94 V-0
- Actuator MaterialPolyphenylene Sulfide (PPS)
Application of FH12-22S-1SH
FH12-22S-1SH Datasheet
FH12-22S-1SH Datasheet , FH12,Solder Retention, Zero Insertion Force (ZIF),-40°C ~ 85°C,Surface Mount, Right Angle,Solder,Phosphor Bronze,Tin-Lead,FFC, FPC,Contacts, Bottom,22,0.039" (1.00mm),0.30mm,0.079" (2.00mm),Flip
FH12-22S-1SH Classification
FFC, FPC (Flat Flexible) Connectors
FAQ about FFC, FPC (Flat Flexible) Connectors
-
1. What is an FPC connector?
FPC connector (Flexible Printed Circuit Connector) is an electronic component designed for connecting flexible printed circuit boards (FPC). It has the characteristics of compact structure, light weight, and strong flexibility, and is widely used in electronic products with high space and weight requirements such as mobile phones, laptops, tablets, wearable devices, and camera modules.
The main features of FPC connectors include:
Miniaturization and high-density integration: can save space and simplify wiring procedures, thereby reducing labor costs.
Excellent flexibility: allows flexible twists and turns to adapt to various complex connection requirements.
Lightweight and low-cost: small size, light weight, easy installation, and strong durability. -
2. What is the rated voltage of FFC?
The rated voltage of FFC is 300V.
FFC cable, also known as Flexible Flat Cable, is a flexible flat cable that is widely used in internal connections of electronic devices. Its main specifications and special features include:
Operating temperature: 80°C
Conductor: 32-16AWG (0.03-1.31mm²) tinned or bare copper strands
Insulation: PVC
Pitch: Common pitches are 0.5mm, 0.8mm, 1.0mm, 1.25mm, 1.27mm, 1.5mm, 2.0mm and 2.54mm
Acid and alkali resistance, oil resistance, heat resistance, moisture resistance, mildew resistance and other characteristics
FFC cables are widely used for data transmission between mobile parts and motherboards, between PCB boards and in miniaturized electrical equipment due to their small size, light weight and high flexibility.
-
3. What is the use of FFC cable?
FFC cable (Flexible Flat Cable) is mainly used to connect mobile parts with motherboards, PCB boards with PCB boards, and data transmission in miniaturized electrical equipment.
FFC cable has the following main features:
High flexibility: The number and spacing of wires can be arbitrarily selected, making wiring more convenient, greatly reducing the volume of electronic products, reducing production costs, and improving production efficiency.
Environmental resistance: It has anti-bending and anti-tensile functions, good flexibility, cold and high temperature resistance.
Wide application: It is suitable for use as a data transmission cable between mobile parts and motherboards, between PCB boards and PCB boards, and in miniaturized electrical equipment.
