Hirose Electric Co Ltd FH34SRJ-26S-0.5SH(50)
The picture is for reference only, please refer to the product specification
- FH34SRJ-26S-0.5SH(50)
- Hirose Electric Co Ltd
- CONN FFC FPC 26POS 0.50MM R/A
- FFC, FPC (Flat Flexible) Connectors
- FH34SRJ-26S-0.5SH(50) Datasheet
- -
- -
-
Lead free / RoHS Compliant - 4951
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is FH34SRJ-26S-0.5SH(50)
Hirose Electric Co Ltd Part Number FH34SRJ-26S-0.5SH(50)（FFC, FPC (Flat Flexible) Connectors）, developed and manufactured by Hirose Electric Co Ltd, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
FH34SRJ-26S-0.5SH(50) is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
FH34SRJ-26S-0.5SH(50) Specifications
- Part NumberFH34SRJ-26S-0.5SH(50)
- CategoryFFC, FPC (Flat Flexible) Connectors
- ManufacturerHirose Electric Co Ltd
- DescriptionCONN FFC FPC 26POS 0.50MM R/A
- Package-
- SeriesFH34SRJ
- FeaturesZero Insertion Force (ZIF)
- Operating Temperature-55°C ~ 85°C
- Mounting TypeSurface Mount, Right Angle
- TerminationSolder
- Contact MaterialPhosphor Bronze
- Contact FinishGold
- Flat Flex TypeFFC, FPC
- Connector/Contact TypeContacts, Top and Bottom
- Number of Positions26
- Pitch0.020" (0.50mm)
- FFC, FCB Thickness0.30mm
- Height Above Board0.039" (1.00mm)
- Locking FeatureRotary Lock, Backlock
- Cable End TypeTapered
- Housing MaterialLiquid Crystal Polymer (LCP), Halogen Free
- Voltage Rating50V
- Material Flammability RatingUL94 V-0
- Actuator MaterialPolyamide (PA), Nylon
Application of FH34SRJ-26S-0.5SH(50)
FH34SRJ-26S-0.5SH(50) Datasheet
FH34SRJ-26S-0.5SH(50) Datasheet , FH34SRJ,Zero Insertion Force (ZIF),-55°C ~ 85°C,Surface Mount, Right Angle,Solder,Phosphor Bronze,Gold,FFC, FPC,Contacts, Top and Bottom,26,0.020" (0.50mm),0.30mm,0.039" (1.00mm),Rotary Lock
FH34SRJ-26S-0.5SH(50) Classification
FFC, FPC (Flat Flexible) Connectors
FAQ about FFC, FPC (Flat Flexible) Connectors
-
1. What is the difference between FFC and FPC connectors?
The main differences between FFC connectors and FPC connectors are in design, application, and performance.
Design Differences
FPC connectors: usually have a multi-layer structure and complex circuit design, are made of conductive materials, and are connected to circuit boards by welding, crimping, etc. FPC connectors are suitable for circuit boards of various shapes and sizes, have extremely high flexibility, and can adapt to different bending and twisting requirements.
FFC connectors: The structure is relatively simple, mainly composed of insulating materials and conductive materials, and are connected to cables by crimping or plugging. FFC connectors are usually used to connect components such as display screens, touch screens, and keyboards. Their flat design makes the cable more stable and reliable during the connection process. -
2. What is an FPC connector?
FPC connector (Flexible Printed Circuit Connector) is an electronic component designed for connecting flexible printed circuit boards (FPC). It has the characteristics of compact structure, light weight, and strong flexibility, and is widely used in electronic products with high space and weight requirements such as mobile phones, laptops, tablets, wearable devices, and camera modules.
The main features of FPC connectors include:
Miniaturization and high-density integration: can save space and simplify wiring procedures, thereby reducing labor costs.
Excellent flexibility: allows flexible twists and turns to adapt to various complex connection requirements.
Lightweight and low-cost: small size, light weight, easy installation, and strong durability. -
3. What is FFC?
FFC (Flexible Flat Cable) is a flexible flat cable, usually composed of flat and soft conductors, such as tinned pure copper wire, made by high-temperature bonding of very thin and flexible adhesive film or paper film 1. FFC has the characteristics of flexibility, lightness, bendability, and anti-twisting. It is widely used in electronic devices as a bridge to connect various components, such as connecting displays and motherboards, touch screens and displays, battery components and control circuit boards. Due to its flexibility and bendability, FFC can achieve more flexible design, optimize the internal space of the device, and has the advantages of small size, light weight, and low cost.
