Harris Corporation HA2-2542-7
The picture is for reference only, please refer to the product specification
- HA2-2542-7
- Harris Corporation
- OPERATIONAL AMPLIFIER
- Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
- HA2-2542-7 Datasheet
- TO-99-8 Metal Can
- Bulk
-
Lead free / RoHS Compliant - 4293
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is HA2-2542-7
Harris Corporation Part Number HA2-2542-7（Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps）, developed and manufactured by Harris Corporation, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
HA2-2542-7 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
HA2-2542-7 Specifications
- Part NumberHA2-2542-7
- CategoryLinear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
- ManufacturerHarris Corporation
- DescriptionOPERATIONAL AMPLIFIER
- PackageBulk
- Series-
- Operating Temperature0°C ~ 75°C
- Mounting TypeThrough Hole
- Package / CaseTO-99-8 Metal Can
- Supplier Device PackageTO-99-8
- Current - Supply30mA
- Output Type-
- Number of Circuits1
- Voltage - Supply, Single/Dual (±)±5V ~ 15V
- Current - Output / Channel100 mA
- -3db Bandwidth-
- Amplifier TypeGeneral Purpose
- Current - Input Bias15 µA
- Voltage - Input Offset5 mV
- Slew Rate350V/µs
- Gain Bandwidth Product70 MHz
Application of HA2-2542-7
HA2-2542-7 Datasheet
HA2-2542-7 Datasheet , Bulk,0°C ~ 75°C,Through Hole,TO-99-8 Metal Can,TO-99-8,30mA,1,±5V ~ 15V,100 mA,General Purpose,15 µA,5 mV,350V/µs,70 MHz
HA2-2542-7 Classification
Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
FAQ about Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
-
1. How to choose the right instrumentation amplifier?
The input common-mode voltage range, gain-bandwidth product, noise performance, power consumption, temperature drift, and common-mode rejection ratio (CMRR) should be considered when selecting an instrumentation amplifier to ensure that it meets the accuracy requirements of a particular application.
-
2. What is Common Mode Rejection Ratio (CMRR) and why is it important for instrumentation amplifiers?
CMRR indicates an instrumentation amplifier's ability to suppress common mode signals, with higher values being better. A high CMRR is especially important in noisy environments to ensure that the amplifier primarily amplifies differential signals and is not affected by common mode interference.
-
3. What is the effect of the op amp's out-of-range voltage on accuracy?
An out-of-phase voltage is the difference in voltage at which the output is not zero when the signal at the input is zero. A large out-of-phase voltage reduces the accuracy of a system, especially in high-gain applications, and selecting an op amp with a low out-of-phase voltage can improve accuracy.
