What is JKM-0011NL

Pulse Electronics Network Part Number JKM-0011NL（Modular Connectors - Jacks With Magnetics）, developed and manufactured by Pulse Electronics Network, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

JKM-0011NL is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

JKM-0011NL Specifications

  • Part NumberJKM-0011NL
  • CategoryModular Connectors - Jacks With Magnetics
  • ManufacturerPulse Electronics Network
  • DescriptionCONN MAGJACK 1PORT 100 BASE-TX
  • Package-
  • SeriesPULSEJACK? JKM
  • FeaturesBoard Guide
  • Operating Temperature0°C ~ 70°C
  • Mounting TypeThrough Hole
  • Applications10/100 Base-TX, AutoMDIX
  • TerminationSolder
  • Contact MaterialPhosphor Bronze
  • Contact FinishGold
  • Orientation90° Angle (Right)
  • Height Above Board0.545" (13.84mm)
  • Connector TypeRJ45
  • ShieldingShielded
  • Number of Rows1
  • Number of Ports1
  • LED ColorDoes Not Contain LED
  • Tab DirectionDown
  • Number of Cores per Jack4

Application of JKM-0011NL

Modular Connectors - Jacks With Magnetics are used in a wide range of electronic devices that require high-quality connectivity and data transmission. In the field of smart phones, magnetic jacks, as an interface for charging and data transmission, provide users with a more convenient and reliable way to charge and connect, while supporting fast charging and high-speed data transmission, improving the user experience. In audio equipment, such as wireless headphones, speakers, etc., the magnetic jack realizes the seamless connection between devices, ensures the stable transmission of audio signals, and enhances the sound quality. In addition, in the fields of industrial automation, medical equipment, aerospace and other fields, modular link-magnetic jacks are also widely used in key equipment such as control systems, testing equipment, and life support systems because of their excellent connection performance and durability, to ensure the accuracy of data transmission and the stability of equipment operation.

JKM-0011NL Datasheet

JKM-0011NL Datasheet , PULSEJACK? JKM,Board Guide,0°C ~ 70°C,Through Hole,10/100 Base-TX, AutoMDIX,Solder,Phosphor Bronze,Gold,90° Angle (Right),0.545" (13.84mm),RJ45,Shielded,1,1,Does Not Contain LED,Down,4

JKM-0011NL Classification

Modular Connectors - Jacks With Magnetics

Modular Connectors - Jacks With Magnetics are a connection component with integrated magnetic interface technology designed for electronic devices that require frequent insertion and removal and require high connection stability. The product is composed of magnetic contact ends, metal pins, insulators and housings, and adopts precision mechanical structure and magnetic attraction principle to achieve fast, accurate and stable connection. The magnetic jack design effectively solves the problem of damage or poor contact caused by improper insertion and removal of traditional jacks, while reducing the wear during connection and prolonging the service life of the equipment. In addition, the modular design makes the connector easy to install, upgrade and maintain to meet the diverse electronic system design needs.

FAQ about Modular Connectors - Jacks With Magnetics

  • 1. Why do we need to integrate magnetic components?

    The main purpose of integrated magnetic components is to meet the requirements of Ethernet standards such as 10/100/1000 Base-T and PoE. Magnetic components provide electrical isolation, signal balance and transient protection, while reducing electromagnetic interference (EMI), ensuring the stability of high-speed data transmission.

  • 2. What Ethernet standards do Modular Connectors - Jacks With Magnetics support?

    These connectors typically support 10/100/1000 Base-T, 2.5Gb/s, 5Gb/s, and 10Gb/s Ethernet standards, and are compatible with PoE (Power over Ethernet) Type 1 to Type 4.

  • 3. How to distinguish different models of Modular Connectors - Jacks With Magnetics?

    Models are usually distinguished by the following features:

    Port configuration: such as 1x1, 1xN or 2xN.

    Rate: such as Cat5e, Cat6 or Cat6A.

    Mounting direction: right angle or vertical mounting.

    Additional features: such as LED indicator or shielding design.
