Amphenol Anytek KI1030530000G
The picture is for reference only, please refer to the product specification
- KI1030530000G
- Amphenol Anytek
- TERM BLOCK PLUG 10POS STR 3.81MM
- Terminal Blocks - Headers, Plugs and Sockets
- KI1030530000G Datasheet
- -
- -
-
Lead free / RoHS Compliant - 4166
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is KI1030530000G
Amphenol Anytek Part Number KI1030530000G（Terminal Blocks - Headers, Plugs and Sockets）, developed and manufactured by Amphenol Anytek, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
KI1030530000G is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
KI1030530000G Specifications
- Part NumberKI1030530000G
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- ManufacturerAmphenol Anytek
- DescriptionTERM BLOCK PLUG 10POS STR 3.81MM
- Package-
- SeriesKI
- TypePlug Housing for Female Sockets
- FeaturesMating Flange
- Mounting TypeFree Hanging (In-Line)
- Termination StyleCrimp
- ColorGreen
- Number of Positions10
- Pitch0.150" (3.81mm)
- Wire Gauge or Range - mm²1-1.2mm²
- Current - UL8A
- Voltage - UL160V
- Number of Levels1
- Positions Per Level10
- Plug Wire Entry180°
Application of KI1030530000G
KI1030530000G Datasheet
KI1030530000G Datasheet , KI,Plug Housing for Female Sockets,Mating Flange,Free Hanging (In-Line),Crimp,Green,10,0.150" (3.81mm),1-1.2mm²,8A,160V,1,10,180°
KI1030530000G Classification
Terminal Blocks - Headers, Plugs and Sockets
FAQ about Terminal Blocks - Headers, Plugs and Sockets
-
1. What is a terminal block plug?
Terminal block plugs are an accessory product used to achieve electrical connections, mainly used to facilitate the connection and disconnection of wires. It is usually composed of a metal conductor encapsulated in an insulating plastic part, with holes at both ends for inserting wires, and tightening or loosening by screws. The design of the terminal plug makes it easy and quick to connect and disconnect the wires without welding or winding, which is particularly suitable for occasions that require frequent connection and disconnection.
Working principle of the terminal
The terminal connects and disconnects the wires by tightening or loosening the screws. Specifically, the wire is inserted into the hole of the terminal and then fixed with screws, so that the wire can be electrically connected through the terminal. When the connection needs to be disconnected, just loosen the screws. -
2. What role does the terminal play in the circuit?
The terminal mainly plays the following roles in the circuit:
Electrical connection: The terminal can reliably connect the wire to the circuit equipment electrically to ensure that the current is correctly transmitted. It provides a safe contact point to prevent the wire from falling off due to excessive force or external factors, thereby ensuring the normal operation of the circuit.
Convenient maintenance: The use of terminal blocks can easily repair and replace the circuit. When a device needs to be replaced or repaired, you only need to loosen the terminal block to remove the wire without changing the connection of other parts, which greatly reduces the difficulty and workload of maintenance.
Prevent contact corrosion: The terminal block is usually made of metal material with good conductivity. Through the connection of the terminal block, corrosion and oxidation at the contact point of the wire can be effectively prevented, and a good electrical connection state can be maintained.
Fixing the wire: The terminal block usually also has the function of fixing the wire. Through the loose and tight contact points, the wire is fixed to the terminal to prevent the wire from loosening or falling off due to external factors, ensuring the stability and safety of the circuit.
Improve system safety: Through the terminal block, the risk of short circuit of exposed wires can be effectively avoided, the occurrence of electrical accidents can be reduced, and the overall safety of the system can be improved.
Support multiple connection methods: The terminal block design is flexible and can support multiple types of connections, such as threaded connection, crimping, welding, etc., to adapt to different application scenarios.
The use scenarios of the terminal block include:
Distribution box and control cabinet: In the power distribution equipment and control cabinet, the terminal block is used to connect the power supply, load and various control equipment to form an electrical control circuit.
Home appliances: In home appliances such as air conditioners and refrigerators, the terminal block is used to connect the power cord to ensure the normal operation of the equipment.
Industrial equipment: In various automation equipment, sensors and actuators, the terminal block is used to transmit signals and power to ensure precise control.
Electrical system: In the power supply system of a building, the terminal block is used to connect cables to ensure the safety and stability of the power supply.
Automotive electrical system: In a car, the terminal block is used to connect batteries, control modules, lights and other electrical equipment to ensure the normal operation of the overall electrical system.
What is a terminal socket?
A terminal socket refers to the metal contact part of a socket used to connect an electrical appliance or a power plug. These terminals are connected to the power line or other electrical equipment through wires or wires, enabling electrical energy to be transmitted to or taken from the equipment in the plug.
Composition and function of terminal sockets
Terminal sockets are usually made of conductive materials such as copper to ensure good electrical conductivity. There are usually multiple terminals on the socket, including active jacks and fixed wiring screws or clips. The jack terminal is a soft metal sheet that can be inserted and fixed to the pins of the plug, while the wiring screw or clip is used to fix the wire by tightening or clamping to ensure a stable electrical connection.
Standards and specifications for terminal sockets
Different countries and regions may have different socket terminal standards and specifications. For example, China's socket terminal standards mainly include national standards GB 2099.3 and GB 1002. GB 2099.3 standard applies to low-voltage household appliance sockets, and specifies the socket's dimensions, terminal form, rated current and voltage and other parameters. GB 1002 standard applies to fixed power sockets, and specifies the socket's installation requirements and electrical connection methods.
-
3. What is the difference between plug and socket connectors?
The main difference between plug and socket connectors lies in their structure and function.
Definition and construction
Plug: A plug is a connector with pins, usually used for external connections, such as the front panel of a device. There are pins on the plug, which are used to insert into the socket to complete the electrical connection.
Socket: A socket is a connector with a jack, usually used for internal connections, such as the interface inside the device. There are contacts on the socket for receiving the plug.
