L717TWC27W2P

Amphenol ICC (Commercial Products) L717TWC27W2P

The picture is for reference only, please refer to the product specification

  • L717TWC27W2P
  • Amphenol ICC (Commercial Products)
  • CONN D-SUB PLUG 27P STR SLDR CUP
  • D-Sub Connectors
  • L717TWC27W2P Datasheet
  • -
  • -
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 1444
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is L717TWC27W2P

Amphenol ICC (Commercial Products) Part Number L717TWC27W2P（D-Sub Connectors）, developed and manufactured by Amphenol ICC (Commercial Products), distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

L717TWC27W2P is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

L717TWC27W2P Specifications

  • Part NumberL717TWC27W2P
  • CategoryD-Sub Connectors
  • ManufacturerAmphenol ICC (Commercial Products)
  • DescriptionCONN D-SUB PLUG 27P STR SLDR CUP
  • Package-
  • SeriesTW
  • FeaturesGrounding Indents
  • Mounting TypePanel Mount
  • TerminationSolder Cup
  • Current Rating7.5A
  • Contact FinishGold
  • Number of Positions27 (25 + 2 Coax or Power)
  • Connector TypePlug, Male Pins
  • Contact Finish Thickness16µin (0.40µm)
  • Number of Rows2
  • Connector StyleD-Sub, Combo
  • Contact TypeSignal and Coax or Power (Not Included)
  • Flange FeatureHousing/Shell (Unthreaded)
  • Shell Material, FinishSteel, Tin Plated
  • Shell Size, Connector Layout4 (DC, C) - 27W2

Application of L717TWC27W2P

D-Sub Connectors play an important role in many fields such as computers and peripherals, communications and networking, industrial automation, and audio and video. These connectors are often used to realize the exchange of signals and data between devices, for example, in computer peripherals, they are used to connect computer peripherals such as keyboards, mice, printers, etc. In communication devices such as network switching devices, modems, routers, etc., D-Sub connectors are used to transmit data and signals. In industrial automation, they are used to connect PLCS (programmable logic controllers) and other control systems. In addition, the D-Sub connector is also an indispensable component in test and measurement equipment for data acquisition and transmission, as well as the interconnection of in-car networks in automotive electronics.

L717TWC27W2P Datasheet

L717TWC27W2P Datasheet , TW,Grounding Indents,Panel Mount,Solder Cup,7.5A,Gold,27 (25 + 2 Coax or Power),Plug, Male Pins,16µin (0.40µm),2,D-Sub, Combo,Signal and Coax or Power (Not Included),Housing/Shell (Unthreaded),Steel, Tin

L717TWC27W2P Classification

D-Sub Connectors

D-Sub Connectors are widely used electronic connectors whose design is characterized by their unique D-shaped metal housing, a shape that not only provides mechanical support but also ensures the correct orientation and alignment of the connector, preventing misinsertion. The D-Sub connector consists of a series of parallel pins or hole pins that are embedded into a D-shaped housing that itself provides protection for the contacts, but also acts as a grounding path and as part of electromagnetic interference (EMI) and radio frequency (RF) shielding. The design principle of the D-Sub connector is based on the physical contact of the metal contact point, and the corresponding interface is connected through the spring-loaded metal contact to form a stable electrical connection. Its features include high reliability, ease of plugging, and a wide range of pin configuration options for varying density signal transmission needs.
