Amphenol ICC (Commercial Products) L777TWA3W3PC798
The picture is for reference only, please refer to the product specification
- L777TWA3W3PC798
- Amphenol ICC (Commercial Products)
- CONN D-SUB PLUG 3POS R/A SOLDER
- D-Sub Connectors
- L777TWA3W3PC798 Datasheet
- -
- -
-
Lead free / RoHS Compliant - 1294
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is L777TWA3W3PC798
Amphenol ICC (Commercial Products) Part Number L777TWA3W3PC798（D-Sub Connectors）, developed and manufactured by Amphenol ICC (Commercial Products), distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
L777TWA3W3PC798 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
L777TWA3W3PC798 Specifications
- Part NumberL777TWA3W3PC798
- CategoryD-Sub Connectors
- ManufacturerAmphenol ICC (Commercial Products)
- DescriptionCONN D-SUB PLUG 3POS R/A SOLDER
- Package-
- SeriesTW
- FeaturesGrounding Indents
- Contact FinishGold
- Number of Positions3 (Power)
- Connector TypePlug, Male Pins
- Contact Finish Thickness30µin (0.76µm)
- Number of Rows1
- Connector StyleD-Sub, Combo
- Contact TypePower
- Shell Material, FinishSteel, Tin Plated
- Shell Size, Connector Layout2 (DA, A) - 3W3
Application of L777TWA3W3PC798
L777TWA3W3PC798 Datasheet
L777TWA3W3PC798 Datasheet , TW,Grounding Indents,Gold,3 (Power),Plug, Male Pins,30µin (0.76µm),1,D-Sub, Combo,Power,Steel, Tin Plated,2 (DA, A) - 3W3
L777TWA3W3PC798 Classification
D-Sub Connectors
FAQ about D-Sub Connectors
-
1. What is a D-SUB connector
The name of the D-SUB connector comes from the D-shaped appearance of its plug. It is a double-row cable connector widely used in computer, industrial automation and communication fields. This connector consists of two parts: a plug and a socket. It is connected through pinholes and pins. It can transmit video, audio and digital signals and provide a large number of grounding points.
The D-SUB connector is a compact and versatile connector mainly used to support power, analog, RF or digital signal transmission. It has a variety of models, options and accessories and is a very economical interconnection solution. -
2. Classification of D-SUB connectors
Solder cup D-Sub connector: This connector meets commercial industrial standards and can be paired with any docking solder cup D-Sub connector. The contacts are electroplated with flash gold, and the connector insulator meets the UL94V-0 standard. The maximum wire size is 20 AWG, and 9, 25, 37 and 50 pin specifications are available.
Crimp D-Sub connector: Crimp D-Sub connectors meet commercial industrial standards and can be used for most standard D-Sub male connectors. Compatible with 20-28 AWG wire range, available in 9, 15, 25 and 50 pin sizes.
Punch-type D-Sub connector: This connector is easily soldered into the through-hole of the printed circuit board or used in many other applications. Solder placement follows a standard footprint, and gold-plated contacts ensure long life. As an industrial standard commercial DB37 female PCB type connector, it has standard mounting holes for application flexibility. -
3. Applications of D-SUB full range of connectors
1. Computer field: D-SUB connectors are widely used in the computer field, such as the connection of external devices such as monitors, keyboards, mice, etc.
2. Communication field: D-SUB connectors can be used for signal transmission between various communication devices, such as telephones, fax machines, routers, etc.
3. Industrial control field: D-SUB connectors are widely used in the industrial control field, such as the connection of PLCs, sensors, actuators and other equipment.
4. Automation field: D-SUB connectors can be used for signal transmission and power supply in automation equipment, such as robots, automated assembly lines, etc.
5. Other fields: In addition to the above fields, D-SUB connectors can also be used in other fields such as security, lighting, and medical equipment. -
4. Problems caused by poor contact of D-SUB connectors
Performance: increased contact resistance, circuit breakage, contact curtain movement, etc.
Causes: inadequate connection, insufficient contact area, dirt, corrosion, oxidation, etc.
Solution: Re-plug the connector, clean the connection part (use alcohol or other cleaning agents), replace the contact or connector.
