LM5064PMH/NOPB

National Semiconductor LM5064PMH/NOPB

The picture is for reference only, please refer to the product specification

  • LM5064PMH/NOPB
  • National Semiconductor
  • LM5064 NEGATIVE VOLTAGE SYSTEM P
  • PMIC - Hot Swap Controllers
  • LM5064PMH/NOPB Datasheet
  • 28-PowerTSSOP (0.173\", 4.40mm Width)
  • Bulk
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 20155
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is LM5064PMH/NOPB

National Semiconductor Part Number LM5064PMH/NOPB（PMIC - Hot Swap Controllers）, developed and manufactured by National Semiconductor, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

LM5064PMH/NOPB is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

LM5064PMH/NOPB Specifications

  • Part NumberLM5064PMH/NOPB
  • CategoryPMIC - Hot Swap Controllers
  • ManufacturerNational Semiconductor
  • DescriptionLM5064 NEGATIVE VOLTAGE SYSTEM P
  • PackageBulk
  • Series-
  • TypeHot Swap Controller, Monitor
  • FeaturesPMBus
  • Voltage - Supply-80V ~ -10V
  • Operating Temperature-40°C ~ 125°C
  • Mounting TypeSurface Mount
  • Package / Case28-PowerTSSOP (0.173\", 4.40mm Width)
  • Supplier Device Package28-HTSSOP
  • Current - Supply6 mA
  • Applications-48V
  • Current - Output (Max)-
  • Number of Channels1
  • Internal Switch(s)No
  • Programmable FeaturesAuto Retry, Circuit Breaker, Current Limit, Fault Timeout, Latched Fault, OVP, Thermal Limit, UVLO

Application of LM5064PMH/NOPB

Hot Swap Controllers are widely used in many fields. In the data center and server space, IT is a key component in building a highly available and scalable IT infrastructure, supporting the hot-swappable operation of servers, storage devices and network equipment to ensure that the data center can run continuously and efficiently. In the field of industrial automation and embedded systems, hot-swappable controllers are widely used in PLC (programmable logic controller), industrial computers and other equipment, supporting the rapid replacement and maintenance of field equipment, improving production efficiency and system reliability. In addition, in the consumer electronics, aerospace, medical electronics and other fields, hot swap controllers also play an important role.

LM5064PMH/NOPB Datasheet

LM5064PMH/NOPB Datasheet , Bulk,Hot Swap Controller, Monitor,PMBus,-80V ~ -10V,-40°C ~ 125°C,Surface Mount,28-PowerTSSOP (0.173\", 4.40mm Width),28-HTSSOP,6 mA,-48V,1,No,Auto Retry, Circuit Breaker, Current Limit, Fault Timeout

LM5064PMH/NOPB Classification

PMIC - Hot Swap Controllers

Hot Swap Controllers are circuits or chips specifically designed to manage the safe plugging and unplugging of devices while they are live. It can implement plug and play functions for hardware devices (such as hard drives, memory modules, network interface cards, etc.) without shutting down the entire system or interrupting the power supply. By precisely controlling the timing of power and signals, the hot-swap controller ensures electrical safety and system stability during device insertion and removal, effectively preventing data loss or hardware damage caused by misoperation or sudden power failure.

FAQ about PMIC - Hot Swap Controllers

  • 1. What is a PMIC hot-swap controller?

    A hot-swap controller is a power management integrated circuit that allows circuit boards or modules to be safely plugged and unplugged while the device is running without causing damage to the device itself or the power system.

  • 2. How does a PMIC hot-swap controller work?

    A hot-swap controller protects system components by limiting inrush current during insertion. It monitors parameters such as current and voltage and triggers protection mechanisms such as overcurrent protection or disconnection of power when they exceed the safe range.

  • 3. How to choose a suitable hot-swap controller?

    When selecting a hot-swap controller, you should consider the system's current and voltage range, protection mechanisms (such as overcurrent protection and thermal shutdown), response time, power dissipation, and other required functions.
