What is LMK04010BISQE/NOPB

National Semiconductor Part Number LMK04010BISQE/NOPB（Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers）, developed and manufactured by National Semiconductor, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

LMK04010BISQE/NOPB is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

LMK04010BISQE/NOPB Specifications

  • Part NumberLMK04010BISQE/NOPB
  • CategoryClock/Timing - Clock Generators, PLLs, Frequency Synthesizers
  • ManufacturerNational Semiconductor
  • DescriptionLMK04010 LOW-NOISE CLOCK JITTER
  • PackageBulk
  • Series-
  • TypeClock Conditioner
  • Voltage - Supply3.15V ~ 3.45V
  • Operating Temperature-40°C ~ 85°C
  • Mounting TypeSurface Mount
  • Package / Case48-WFQFN Exposed Pad
  • Supplier Device Package48-WQFN (7x7)
  • Output2VPECL, LVPECL
  • Frequency - Max1.296GHz
  • Number of Circuits1
  • InputLVCMOS, LVDS, LVPECL
  • PLLYes
  • Ratio - Input:Output2:5
  • Differential - Input:OutputYes/Yes
  • Divider/MultiplierYes/Yes

Application of LMK04010BISQE/NOPB

Clock Generators are widely used in computer chips, digital circuits, radio communication, audio and video equipment and other electronic equipment. The clock signal generated by it is the basis for the normal operation of these devices, ensuring the stable transmission and processing of data. PLL (phase-locked Loop) is mainly used to detect and track the frequency and Phase of the input signal and convert it into a stable output signal. It can change the frequency of the input signal to achieve a specific purpose, such as signal synchronization, frequency conversion, etc. Frequency Synthesizers generate a series of high-precision frequency sources with a certain frequency interval through synthesis technology to provide the required frequency signals for various electronic devices. It is widely used in applications requiring accurate frequency control, such as radar, communications, electronic countermeasures and other fields.

LMK04010BISQE/NOPB Datasheet

LMK04010BISQE/NOPB Datasheet , Bulk,Clock Conditioner,3.15V ~ 3.45V,-40°C ~ 85°C,Surface Mount,48-WFQFN Exposed Pad,48-WQFN (7x7),2VPECL, LVPECL,1.296GHz,1,LVCMOS, LVDS, LVPECL,Yes,2:5,Yes/Yes,Yes/Yes

LMK04010BISQE/NOPB Classification

Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers

Clock Generators are circuits or devices used to generate stable and precise pulses of electrical signals. The clock signal generated by it provides a unified time benchmark for various electronic devices, ensuring that the components of the device can synchronize operations and actions.PLL (Phase Locked Loop and phase-locked Loop) is a kind of circuit is used to control the frequency and Phase. It can convert the frequency and phase of an input signal into the frequency and phase of another output signal to realize the synchronization of frequency and phase. Frequency Synthesizers are devices that use one or more standard signals to generate a large number of discrete frequency signals through various technical approaches. It can realize precise control and adjustment of frequency to meet the needs of different application scenarios.
