NXP USA Inc. MK60DN256ZVLL10
The picture is for reference only, please refer to the product specification
- MK60DN256ZVLL10
- NXP USA Inc.
- IC MCU 32BIT 256KB FLASH 100LQFP
- Embedded - Microcontrollers
- MK60DN256ZVLL10 Datasheet
- 100-LQFP
- Tray
-
Lead free / RoHS Compliant - 3368
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is MK60DN256ZVLL10
NXP USA Inc. Part Number MK60DN256ZVLL10（Embedded - Microcontrollers）, developed and manufactured by NXP USA Inc., distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
MK60DN256ZVLL10 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
MK60DN256ZVLL10 Specifications
- Part NumberMK60DN256ZVLL10
- CategoryEmbedded - Microcontrollers
- ManufacturerNXP USA Inc.
- DescriptionIC MCU 32BIT 256KB FLASH 100LQFP
- PackageTray
- SeriesKinetis K60
- Operating Temperature-40°C ~ 105°C (TA)
- Mounting TypeSurface Mount
- Package / Case100-LQFP
- Supplier Device Package100-LQFP (14x14)
- Voltage - Supply (Vcc/Vdd)1.71V ~ 3.6V
- Speed100MHz
- Number of I/O66
- EEPROM Size-
- Core ProcessorARM® Cortex®-M4
- RAM Size64K x 8
- Core Size32-Bit
- ConnectivityCANbus, EBI/EMI, Ethernet, I²C, IrDA, SD, SPI, UART/USART, USB, USB OTG
- PeripheralsDMA, I²S, LVD, POR, PWM, WDT
- Program Memory Size256KB (256K x 8)
- Program Memory TypeFLASH
- Data ConvertersA/D 33x16b; D/A 1x12b
- Oscillator TypeInternal
Application of MK60DN256ZVLL10
MK60DN256ZVLL10 Datasheet
MK60DN256ZVLL10 Datasheet , Tray,Kinetis K60,-40°C ~ 105°C (TA),Surface Mount,100-LQFP,100-LQFP (14x14),1.71V ~ 3.6V,100MHz,66,ARM® Cortex®-M4,64K x 8,32-Bit,CANbus, EBI/EMI, Ethernet, I²C, IrDA, SD, SPI, UART/USART, USB, USB
MK60DN256ZVLL10 Classification
Embedded - Microcontrollers
FAQ about Embedded - Microcontrollers
-
1. What is an embedded microcontroller?
An embedded microcontroller is a device that integrates an entire computer system into a single chip. It usually includes functional modules such as a central processing unit, memory, input and output ports, and timers, all of which are integrated on a single chip. This design enables embedded microcontrollers to perform specific tasks with high flexibility and efficiency.
The main features of embedded microcontrollers include:
Highly integrated: multiple functions such as CPU, memory, and I/O interface are integrated on a single chip, reducing the number of components and system volume.
Strong specialization: Optimized for specific application scenarios, providing a specific combination of processing power, memory, and input and output interfaces.
Efficient and reliable: The integrated design makes the system more stable and reliable, reducing the connection of external components and signal interference.
High flexibility: According to different application requirements, embedded microcontrollers can have multiple derivative products, each with the same processor core, but different memory and peripheral configurations to adapt to different application scenarios. -
2. What is an embedded system controller?
An embedded system controller is a microcomputer system designed specifically for a specific purpose. It integrates key components such as processors, memory, input and output interfaces, etc. to achieve real-time control and data processing of embedded systems. It is widely used in electronic products, automobiles, industrial automation and other fields, and is an important foundation for modern intelligent production.
Embedded system controllers have the following characteristics:
High performance: Embedded system controllers usually have high-performance processing capabilities and can handle complex computing tasks.
Low power consumption: Compared with personal computers or servers, embedded system controllers usually have lower power consumption and are suitable for long-term operation scenarios.
High reliability: Due to the particularity of the application scenario, the embedded system controller needs to have high reliability and be able to work stably in harsh environments.
Rich peripheral interfaces: In order to adapt to different application requirements, embedded system controllers usually provide rich peripheral interfaces to facilitate communication and data exchange with other devices.
The application fields of embedded system controllers are very wide, including:
Electronic products: such as smart watches, smart home devices, etc.
Automotive electronics: such as in-car entertainment systems, intelligent driving assistance systems, etc.
Industrial automation: such as industrial control systems, automated production lines, etc.
Medical equipment: such as medical imaging equipment, monitoring instruments, etc.
Communication equipment: such as base station equipment, wireless communication terminals, etc.
What is the difference between embedded microcontrollers and external microcontrollers?
The main difference between embedded microcontrollers and external microcontrollers lies in their application scenarios and integration. Embedded microcontrollers are computer systems designed specifically for embedding into object systems. They usually integrate necessary components such as microprocessor cores, memory, and peripheral interfaces, and are mainly used to control and execute specific tasks. External microcontrollers usually refer to independent microcontroller units. Although they also have similar components, they are mainly used for more complex computing and processing tasks.
Embedded microcontrollers are often used in embedded systems, which are usually composed of a series of electronic components and have specific functions. As the core component of the system, embedded microcontrollers are responsible for controlling, monitoring or assisting the operation of equipment, machines and workshops. They are widely used in various fields such as home appliances, automobiles, industrial control, medical equipment, etc., with the characteristics of low power consumption and high performance.
External microcontrollers are usually used in scenarios that require higher computing power and more complex processing. They can exist independently of embedded systems and perform a variety of tasks such as data processing and communication. External microcontrollers are widely used in personal computers, servers, industrial automation and other fields, and can handle more complex data and tasks. -
3. Is Raspberry Pi an embedded system?
Raspberry Pi is an embedded system. Raspberry Pi is a single-board computer based on ARM architecture with rich input and output interfaces and powerful computing power. It can run the Linux operating system and support multiple programming languages such as Python and C++. Due to its compact size and powerful functions, Raspberry Pi is widely used in various embedded systems and robotics projects.
Features of Raspberry Pi include:
Based on ARM architecture: Raspberry Pi adopts ARM architecture, which is an architecture widely used in embedded systems with low power consumption and high efficiency.
Rich interfaces: It has USB interface, Fast Ethernet interface, SD slot, HDMI output interface, etc., and can connect a variety of peripherals.
Open source software support: It supports multiple programming languages and a large number of open source software libraries, which is convenient for development and expansion.
Wide application: It is often used to build routers, smart cars, smart homes, servers and other applications.
Disadvantages of Raspberry Pi include:
Single 5V power supply: The power supply design is simple, which may cause unstable operation of peripherals.
Bandwidth limitation: The USB interface has limited bandwidth and may encounter performance bottlenecks when transmitting large amounts of data.
