Vishay Beyschlag/Draloric/BC Components MKT1820468635
The picture is for reference only, please refer to the product specification
- MKT1820468635
- Vishay Beyschlag/Draloric/BC Components
- CAP FILM 0.68UF 10% 630VDC RAD
- Film Capacitors
- MKT1820468635 Datasheet
- Radial
- Bulk
-
Lead free / RoHS Compliant - 2025
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is MKT1820468635
Vishay Beyschlag/Draloric/BC Components Part Number MKT1820468635（Film Capacitors）, developed and manufactured by Vishay Beyschlag/Draloric/BC Components, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
MKT1820468635 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
MKT1820468635 Specifications
- Part NumberMKT1820468635
- CategoryFilm Capacitors
- ManufacturerVishay Beyschlag/Draloric/BC Components
- DescriptionCAP FILM 0.68UF 10% 630VDC RAD
- PackageBulk
- SeriesMKT1820
- Features-
- Operating Temperature-55°C ~ 125°C
- Mounting TypeThrough Hole
- Package / CaseRadial
- ApplicationsDC Link, DC Filtering
- Tolerance±10%
- Size / Dimension1.240" L x 0.531" W (31.50mm x 13.50mm)
- TerminationPC Pins
- Voltage Rating - AC220V
- Voltage Rating - DC630V
- Lead Spacing1.083\" (27.50mm)
- Ratings-
- Height - Seated (Max)0.925\" (23.50mm)
- Capacitance0.68 µF
- ESR (Equivalent Series Resistance)-
- Dielectric MaterialPolyester, Metallized
Application of MKT1820468635
MKT1820468635 Datasheet
MKT1820468635 Datasheet , Bulk,MKT1820,-55°C ~ 125°C,Through Hole,Radial,DC Link, DC Filtering,±10%,1.240" L x 0.531" W (31.50mm x 13.50mm),PC Pins,220V,630V,1.083\" (27.50mm),0.925\" (23.50mm),0.68 µF,Polyester, Metallized
MKT1820468635 Classification
Film Capacitors
FAQ about Film Capacitors
-
1. What are the uses of film capacitors?
High-frequency filtering, power decoupling, power noise bypass
The main uses of film capacitors include high-frequency filtering, power decoupling, power noise bypass, etc. In electronic devices, film capacitors are widely used in various circuits due to their high insulation impedance, wide frequency response and self-healing properties.
Specific application scenarios
High-frequency filtering: Film capacitors have excellent high-frequency insulation performance, and the capacitance and loss angle are independent of frequency in a large frequency range and change little with temperature, so they are often used in high-frequency filtering circuits.
Power decoupling: In car audio systems, film capacitors are used for power decoupling to ensure stable power supply and avoid noise caused by feedback generated by the power supply.
Power noise bypass: Film capacitors are also widely used for power noise bypass (reverse cross-connection) to reduce the impact of power noise on the circuit.
Different types of applications
CBB film capacitors: widely used in circuit boards because of their high insulation impedance and wide frequency response.
Organic film capacitors: Made of materials such as polypropylene film and polyester film, they have excellent performance, a wide variety of varieties, and a wide range of applications. They are suitable for a variety of electronic devices.
-
2. Is a film capacitor AC or DC?
AC, DC
Film capacitors can be used in both AC and DC circuits. According to the current type, film capacitors can be divided into DC film capacitors and AC film capacitors.
DC film capacitors
DC film capacitors are mainly used in DC circuits and have the following characteristics:
Large capacity: has a higher capacitance.
Low withstand voltage: the withstand voltage value is relatively low.
Polarity: has positive and negative poles.
Application scenarios: commonly used in motor drives, uninterruptible power supplies (UPS), solar inverters, electronic ballasts, small automotive motors, household appliances, etc.
AC film capacitors
AC film capacitors are mainly used in AC circuits and have the following characteristics:
Small capacity: relatively small capacitance.
High withstand voltage: high withstand voltage value.
Pass AC, block DC: conduct electricity in AC circuits, equivalent to open circuits in DC circuits.
Application scenarios: widely used in industrial AC power supplies, asynchronous motor starting and operation, uninterruptible power supplies (UPS) and output filters of photovoltaic inverters, etc. -
3. What are the alternatives to film capacitors?
CL21 capacitors, MPB capacitors, CBB13, CBB81, MMKP82 capacitors
Alternatives to film capacitors mainly include CL21 capacitors, MPB capacitors, CBB13, CBB81 and MMKP82 capacitors. These alternatives have their own advantages and disadvantages in performance and applicable scenarios, and the specific choice depends on specific needs.
CL21 capacitors
CL21 capacitors and CBB22 capacitors can replace each other in applications such as filtering. CL21 capacitors are more stable than CBB22 capacitors under high-frequency conditions, so CL21 capacitors are more preferred in high-frequency circuits. However, CL21 capacitors are more expensive and perform better in high-frequency circuits.
MPB capacitors
MPB capacitors are boxed metallized polypropylene film capacitors with the same core as CBB22 capacitors, but with a plastic shell, which has better resistance to high temperature, moisture and sealing performance. MPB capacitors can replace CBB22 capacitors in high frequency, DC, AC and pulse high current applications, but their prices are relatively high.
CBB13, CBB81 and MMKP82 capacitors
These capacitors have a higher voltage resistance, up to 3000V, and are suitable for applications requiring higher voltages. However, they are also relatively expensive and larger in size.
