SK32BHR5G

Taiwan Semiconductor Corporation SK32BHR5G

The picture is for reference only, please refer to the product specification

  • SK32BHR5G
  • Taiwan Semiconductor Corporation
  • DIODE SCHOTTKY 20V 3A DO214AA
  • Diodes - Rectifiers - Single
  • SK32BHR5G Datasheet
  • DO-214AA, SMB
  • Tape & Reel (TR)
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 1733
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Delivery Services:
Payment Information
Payment Methods:
Shipping Information

What is SK32BHR5G

Taiwan Semiconductor Corporation Part Number SK32BHR5G（Diodes - Rectifiers - Single）, developed and manufactured by Taiwan Semiconductor Corporation, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

SK32BHR5G is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

SK32BHR5G Specifications

  • Part NumberSK32BHR5G
  • CategoryDiodes - Rectifiers - Single
  • ManufacturerTaiwan Semiconductor Corporation
  • DescriptionDIODE SCHOTTKY 20V 3A DO214AA
  • PackageTape & Reel (TR)
  • SeriesAutomotive, AEC-Q101
  • Mounting TypeSurface Mount
  • Package / CaseDO-214AA, SMB
  • Supplier Device PackageDO-214AA (SMB)
  • Diode TypeSchottky
  • Current - Average Rectified (Io)3A
  • Voltage - Forward (Vf) (Max) @ If500 mV @ 3 A
  • Current - Reverse Leakage @ Vr500 µA @ 20 V
  • Capacitance @ Vr, F-
  • Voltage - DC Reverse (Vr) (Max)20 V
  • SpeedFast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr)-
  • Operating Temperature - Junction-55°C ~ 125°C

Application of SK32BHR5G

Rectifiers are used in an extremely wide range of applications, covering almost all situations where DC power is required. In terms of power supply equipment, rectifiers are widely used in power transformers, switching power supplies, etc., to provide stable DC power for various electronic equipment. In the field of lighting, with the popularity of new light sources such as LED, rectifier-single also plays an important role, it can convert alternating current into direct current to drive LED lights and other light-emitting devices, to achieve energy-efficient lighting effects. In addition, in many fields such as industrial automation, communication equipment, automotive electronics, medical equipment, rectifiers also play an irreplaceable role. Especially in the field of industrial automation, rectifiers - provide a stable DC power supply for motors, frequency converters and other equipment, ensuring the stable operation of the production line and efficient production.

SK32BHR5G Datasheet

SK32BHR5G Datasheet , Tape & Reel (TR),Automotive, AEC-Q101,Surface Mount,DO-214AA, SMB,DO-214AA (SMB),Schottky,3A,500 mV @ 3 A,500 µA @ 20 V,20 V,Fast Recovery =< 500ns, > 200mA (Io),-55°C ~ 125°C

SK32BHR5G Classification

Diodes - Rectifiers - Single

Rectifiers - Single refers to a standalone rectifier device, which usually contains one or several rectifying elements (such as diodes), and its core function is to convert alternating current (AC) to direct current (DC). Specifically, it takes advantage of the unidirectional conductivity of semiconductor diodes, allowing current to pass in only one direction, thus enabling the conversion from fluctuating alternating current to stable direct current.

FAQ about Diodes - Rectifiers - Single

  • 1. What is the working principle of a single rectifier diode?

    A rectifier diode conducts current when forward biased, converting the positive half wave of alternating current into direct current. When reverse biased, the diode blocks the current, thereby preventing the negative half wave from passing through and achieving rectification effect.

  • 2. How to choose the appropriate rectifier diode?

    When making a choice, the following factors need to be considered:

    Current capacity: Determine the maximum current that the diode needs to handle.

    Reverse voltage: Ensure that the reverse voltage of the diode can withstand the highest voltage in the circuit.

    Forward voltage drop: A lower forward voltage drop can improve circuit efficiency.

    Recovery time: For high-frequency applications, choose fast recovery or Schottky diodes.

  • 3. What is the difference between a single rectifier diode and a bridge rectifier?

    A single rectifier diode can only rectify the positive half wave of AC power (half wave rectification), while a bridge rectifier composed of four diodes can rectify the positive and negative half waves of AC power (full wave rectification), with higher efficiency and smoother output.
