Switchcraft Inc. TA3MX
The picture is for reference only, please refer to the product specification
- TA3MX
- Switchcraft Inc.
- CONN RCPT CORD 3POS MALE MINI
- Circular Connectors
- TA3MX Datasheet
- -
- -
-
Lead free / RoHS Compliant - 26005
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is TA3MX
Switchcraft Inc. Part Number TA3MX（Circular Connectors）, developed and manufactured by Switchcraft Inc., distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
TA3MX is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
TA3MX Specifications
- Part NumberTA3MX
- CategoryCircular Connectors
- ManufacturerSwitchcraft Inc.
- DescriptionCONN RCPT CORD 3POS MALE MINI
- Package-
- SeriesTini Q-G? TA-X
- FeaturesBackshell, Cable Clamp, Strain Relief
- Mounting TypeFree Hanging (In-Line)
- TerminationSolder
- Current Rating5A
- Voltage - Rated125VAC
- Contact FinishSilver
- OrientationKeyed
- Number of Positions3
- Connector TypeReceptacle, Male Pins
- Shell Size - InsertMini XLR
- Fastening TypeLatch Lock
- Shell Material, FinishCopper Alloy, Nickel Plated
Application of TA3MX
TA3MX Datasheet
TA3MX Datasheet , Tini Q-G? TA-X,Backshell, Cable Clamp, Strain Relief,Free Hanging (In-Line),Solder,5A,125VAC,Silver,Keyed,3,Receptacle, Male Pins,Mini XLR,Latch Lock,Copper Alloy, Nickel Plated
TA3MX Classification
Circular Connectors
FAQ about Circular Connectors
-
1. What is a circular connector
A circular connector is a cylindrical electronic connector with a circular mating surface. It belongs to the fifth category of the interconnection classification and is mainly used for interconnection between devices. The design of circular connectors includes many types, such as low-frequency circular connectors, RF coaxial connectors and audio connectors, etc., with a wide operating temperature range from -55℃ to +150℃.
-
2. How to cnlinko 4 pin power industrial circular connector
1. Confirm the voltage, current and frequency:
2. Choose the right environment: In normal environment, regular plugs and sockets can be used. IP67 anti-immersion plugs and sockets are used in harsh environment.
3. Pay attention to the installation of the connector: Make sure that the socket used to install the connector on the power supply line has a cover to prevent electric shock.
4. Check the connector status: Before use, check whether the model, code, number, plug position and direction of the connector meet the requirements of the design and process documents. 5. Correct plugging and unplugging operation: Before plugging, check whether the code, interface, etc. of the plug to be plugged in correspond to the socket, and accurately position them. -
3. How to remove the circular plastic terminal head
1. Use scissors or flat-nosed pliers to cut off or remove the outer shell on the circular plastic terminal head to expose the internal wiring part.
2. Use a screwdriver to loosen the screws on the terminal head to remove the terminal head.
3. Gently pull the terminal head by hand to remove it from the wire.
4. If the terminal head is very tight, you can use flat-nosed pliers or pliers to increase the removal force.
5. If you need to replace a new terminal head, you can insert the new terminal head into the wire and tighten the screws to ensure that the wiring is firm. -
4. How to remove a circular electrical connector
1. Loosen the locking ring. To remove a circular electrical connector, you first need to loosen the locking ring;
2. Remove the sealant. There is a sealant on the connector, which needs to be removed first.
3. Remove the terminal. First, loosen the terminal fastening or open the slot, and then carefully separate the plug and the socket;
