What is TLP383(D4BLLTL,E

Toshiba Semiconductor and Storage Part Number TLP383(D4BLLTL,E（Optoisolators - Transistor, Photovoltaic Output）, developed and manufactured by Toshiba Semiconductor and Storage, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

TLP383(D4BLLTL,E is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

TLP383(D4BLLTL,E Specifications

  • Part NumberTLP383(D4BLLTL,E
  • CategoryOptoisolators - Transistor, Photovoltaic Output
  • ManufacturerToshiba Semiconductor and Storage
  • DescriptionOPTOISO 5KV TRANSISTOR SO6L
  • Package6-SOIC (0.173", 4.40mm Width) 4 Leads
  • Series-
  • Operating Temperature-55°C ~ 125°C
  • Mounting TypeSurface Mount
  • Package / Case6-SOIC (0.173", 4.40mm Width), 4 Leads
  • Supplier Device Package6-SO
  • Output TypeTransistor
  • Voltage - Output (Max)80V
  • Number of Channels1
  • Input TypeDC
  • Voltage - Isolation5000Vrms
  • Rise / Fall Time (Typ)2µs, 3µs
  • Voltage - Forward (Vf) (Typ)1.25V
  • Current - DC Forward (If) (Max)50mA
  • Current - Output / Channel50mA
  • Current Transfer Ratio (Min)200% @ 500µA
  • Current Transfer Ratio (Max)400% @ 500µA
  • Vce Saturation (Max)300mV
  • Turn On / Turn Off Time (Typ)3µs, 3µs

Application of TLP383(D4BLLTL,E

Transistor optical isolators are widely used in industrial automation, data communication, medical equipment, power management and aerospace and other fields for isolating and transmitting various signals to ensure the stability and reliability of the system. The photoelectric output optical isolator is especially suitable for occasions where the signal output quality is required, such as high-precision measurement and signal transmission in control systems. In addition, it is also widely used in data communication, medical equipment and other fields.

TLP383(D4BLLTL,E Datasheet

TLP383(D4BLLTL,E Datasheet , 6-SOIC (0.173", 4.40mm Width) 4 Leads,-55°C ~ 125°C,Surface Mount,6-SOIC (0.173", 4.40mm Width), 4 Leads,6-SO,Transistor,80V,1,DC,5000Vrms,2µs, 3µs,1.25V,50mA,50mA,200% @ 500µA,400% @ 500µA,300mV,3µs

TLP383(D4BLLTL,E Classification

Optoisolators - Transistor, Photovoltaic Output

Optoisolators-Transistor and Photovoltaic Output are two kinds of electronic components designed based on the principle of photoelectric effect, which are used to achieve electrical isolation and signal transmission between different circuits. The basic structure of the two types of optical isolators is similar, both consisting of a light emitting diode (LED) and a photodetector, but their type of photodetector is different: a transistor optical isolator uses a phototransistor as a photodetector, while a photooutput optical isolator uses a photodiode or other type of photosensor.

FAQ about Optoisolators - Transistor, Photovoltaic Output

  • 1. What is a transistor output optocoupler?

    A transistor output optocoupler is a photocoupler, and its internal structure usually includes a light-emitting diode (LED) and a phototransistor. When the electrical signal at the input end drives the LED to emit light, the phototransistor generates a photocurrent after receiving the light signal, and then outputs it after amplification, thereby completing the "electricity -> light -> electricity" conversion and realizing the isolation between input and output.

  • 2. What is a transistor output?

    Transistor output is an output mode in circuit control, mainly used for controlling actuators (such as motors and electromagnets) in automation equipment. Transistor output realizes the switching control of the circuit through a semiconductor device, a transistor. As an electronic switch, the transistor has the characteristics of fast response and high-frequency action, and is suitable for application scenarios that require high-speed switching.

  • 3. What is the role of the optical isolator?

    The main function of the optical isolator is to allow light to pass in one direction and prevent light from passing in the opposite direction, thereby limiting the transmission direction of light and ensuring that light can only be transmitted in one direction. This characteristic makes the optical isolator play an important role in optical fiber communication systems, which can isolate reflected light and prevent the adverse effects of backward transmission light on the light source and optical path system.
