Texas Instruments TPD2E007DCKR
The picture is for reference only, please refer to the product specification
- TPD2E007DCKR
- Texas Instruments
- TVS DIODE SC70-3
- TVS - Diodes
- TPD2E007DCKR Datasheet
- SC-70, SOT-323
- SC-70, SOT-323
-
Lead free / RoHS Compliant - 719
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is TPD2E007DCKR
Texas Instruments Part Number TPD2E007DCKR（TVS - Diodes）, developed and manufactured by Texas Instruments, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
TPD2E007DCKR is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
TPD2E007DCKR Specifications
- Part NumberTPD2E007DCKR
- CategoryTVS - Diodes
- ManufacturerTexas Instruments
- DescriptionTVS DIODE SC70-3
- PackageSC-70, SOT-323
- Series-
- TypeZener
- Operating Temperature-40°C ~ 85°C (TA)
- Mounting TypeSurface Mount
- Package / CaseSC-70, SOT-323
- Supplier Device PackageSC-70-3
- ApplicationsGeneral Purpose
- Voltage - Reverse Standoff (Typ)13V (Max)
- Voltage - Breakdown (Min)14V
- Power Line ProtectionNo
- Bidirectional Channels2
Application of TPD2E007DCKR
TPD2E007DCKR Datasheet
TPD2E007DCKR Datasheet , SC-70, SOT-323,Zener,-40°C ~ 85°C (TA),Surface Mount,SC-70, SOT-323,SC-70-3,General Purpose,13V (Max),14V,No,2
TPD2E007DCKR Classification
TVS - Diodes
FAQ about TVS - Diodes
-
1. What is the difference between TVS and ordinary diodes?
The main difference between TVS diodes and ordinary diodes lies in their working principle, application scenarios and characteristics.
Working principle and application scenarios
TVS diode: TVS diode (Transil Voltage Suppressor) is a high-efficiency protection device that stabilizes and suppresses overvoltage based on the breakdown effect of PN junction. When the voltage exceeds its breakdown voltage, the TVS diode will conduct quickly and release the overvoltage to ground, thus protecting the precision components in the circuit from damage by surge pulses. TVS diodes are widely used in computer systems, communication equipment, automotive electronics, household appliances and other fields to suppress transient overvoltage and electromagnetic interference.
Ordinary Diode: The main function of an ordinary diode is unidirectional conductivity, allowing current to pass in one direction and blocking reverse current. They are widely used in rectification, signal modulation, power management and other scenarios.
Feature comparison
Current size: The Zener breakdown current of TVS diodes is small, usually around 1mA, while the breakdown current of ordinary diodes is larger.
Classification: TVS diodes are divided into unipolar and bipolar according to polarity; ordinary diodes are divided into low-voltage and high-voltage types according to the level of voltage regulation, as well as N-type and P-type materials.
Voltage regulation characteristics: The voltage characteristics of TVS diodes are nonlinear, the resistance before breakdown is high, and the voltage remains constant after breakdown; the voltage of ordinary diodes remains constant at the critical reverse breakdown point, realizing the voltage stabilization function.
-
2. What is the difference between TVS and ESD diodes?
The main difference between TVS diodes and ESD diodes is their working principle, application scenarios and characteristics.
Working principle and application scenarios
TVS diodes (Transient Voltage Suppressors): TVS diodes are mainly used to suppress transient voltages and prevent components in the circuit from being damaged by surge voltages. When the two poles of the TVS diode are impacted by reverse transient high energy, it can change the high impedance to low impedance in a very short time, absorb the surge power, and protect the precision components in the circuit1. TVS diodes are suitable for protection against various surge pulses, such as lightning strikes, large-capacity load switching, etc.
ESD diode (Electro-Static discharge): ESD diode is mainly used to prevent static electricity and prevent damage to electronic equipment caused by electrostatic discharge. ESD diodes have low capacitance values, typically between 1 and 3.5 picofarad (PF), to accommodate the rapid changes in electrostatic discharge. ESD diodes are suitable for board-level protection, especially in high-speed USB and I/O interfaces, which have higher requirements for electrostatic discharge.
-
3. How do TVS diodes fail?
The failure modes of TVS diodes mainly include short circuit failure, open circuit failure and performance degradation. These failure modes can have a serious impact on the normal operation and protection functions of the circuit.
short circuit fault
Short circuit failure is one of the most common failure modes of TVS diodes. When a TVS diode is short-circuited, it changes to a low-impedance state, allowing a large amount of current to pass through, which may cause the circuit to not function properly and may even damage other circuit components. Causes of short circuit faults include:
Thermal breakdown: In a high temperature environment or when subjected to excessive transient energy impact, the PN junction of the TVS diode may undergo thermal breakdown, resulting in a short circuit.
Over-electrical stress: When the transient pulse energy exceeds the energy that the TVS can withstand, it will cause over-electrical stress damage and even directly cause burnout.
Manufacturing process issues: Such as chip bonding interface voids, mesa defects, strong accumulation layer or strong inversion layer on the surface, chip cracks, uneven impurity diffusion, etc., which may cause short circuit failures of TVS diodes during manufacturing or use.
