Texas Instruments TPL0202-10MRTER
The picture is for reference only, please refer to the product specification
- TPL0202-10MRTER
- Texas Instruments
- IC DGT POT 10KOHM 256TAP 16WQFN
- Digital Potentiometers ICs
- TPL0202-10MRTER Datasheet
- 16-WFQFN Exposed Pad
- Tape & Reel (TR)
-
Lead free / RoHS Compliant - 17573
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is TPL0202-10MRTER
Texas Instruments Part Number TPL0202-10MRTER（Digital Potentiometers ICs）, developed and manufactured by Texas Instruments, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
TPL0202-10MRTER is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
TPL0202-10MRTER Specifications
- Part NumberTPL0202-10MRTER
- CategoryDigital Potentiometers ICs
- ManufacturerTexas Instruments
- DescriptionIC DGT POT 10KOHM 256TAP 16WQFN
- PackageTape & Reel (TR)
- Series-
- Features-
- InterfaceSPI
- Voltage - Supply2.7V ~ 5.5V
- Operating Temperature-40°C ~ 85°C
- Mounting TypeSurface Mount
- Package / Case16-WFQFN Exposed Pad
- Supplier Device Package16-WQFN (3x3)
- Tolerance±20%
- Number of Circuits2
- ConfigurationPotentiometer
- Memory TypeNon-Volatile
- TaperLinear
- Number of Taps256
- Resistance (Ohms)10k
- Temperature Coefficient (Typ)132ppm/°C
- Resistance - Wiper (Ohms) (Typ)25
Application of TPL0202-10MRTER
TPL0202-10MRTER Datasheet
TPL0202-10MRTER Datasheet , Tape & Reel (TR),SPI,2.7V ~ 5.5V,-40°C ~ 85°C,Surface Mount,16-WFQFN Exposed Pad,16-WQFN (3x3),±20%,2,Potentiometer,Non-Volatile,Linear,256,10k,132ppm/°C,25
TPL0202-10MRTER Classification
Digital Potentiometers ICs
FAQ about Digital Potentiometers ICs
-
1. What are the components of a digital potentiometer?
A digital potentiometer mainly consists of two parts: a voltage divider and a controller.
The voltage divider consists of a series of resistor elements that divide the input voltage according to a certain ratio. Each resistor element is connected to the input pin of the controller. The controller is responsible for reading the control signal and opening or closing the corresponding switch according to the level of the signal, thereby changing the total resistance. -
2. What is the difference between IC and digital IC?
The main difference between IC and digital IC is that they process different types of signals. IC processes continuously changing analog signals, while digital IC processes discrete digital signals.
Specifically, IC (integrated circuit) is a microelectronic device or component that uses a certain process to interconnect transistors, resistors, capacitors and other components and wiring, and is made on a small piece of semiconductor wafer, and then packaged to form a circuit with specific functions. Integrated circuits have the advantages of small size, light weight, long life and high reliability.
Digital IC specializes in processing digital signals, which are discrete in time and amplitude. The design focus of digital IC is on the optimization of logical relationships and system architecture, pursuing the smallest line width, lowest power consumption and fastest transmission speed. Examples of digital ICs include CPUs, microprocessors, microcontrollers, etc., which are widely used in computers and other digital systems. -
3. How to use digital potentiometers?
Digital potentiometers are a new type of CMOS digital and analog mixed signal processing integrated circuit that replaces traditional mechanical potentiometers. It is controlled by digital inputs, produces an analog output, and has precise resistance adjustment functions.
The basic components of digital potentiometers include voltage dividers and controllers. The voltage divider consists of a series of resistor elements that divide the input voltage according to a certain ratio; the controller is responsible for reading the control signal and opening or closing the corresponding switch according to the high or low signal, thereby changing the size of the total resistance.
When using a digital potentiometer, you first need to make a hardware connection. For example, connect the encoding mode of the EC11 digital potentiometer to a specific pin of the timer. Then, the mode of the encoder is controlled by software to adjust the digital potentiometer. The specific operations include entering the potentiometer mode, adjusting the value, and saving the setting.
