What is WR-160PB-VF50-N1

JAE Electronics Part Number WR-160PB-VF50-N1（Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)）, developed and manufactured by JAE Electronics, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.

WR-160PB-VF50-N1 is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.

WR-160PB-VF50-N1 Specifications

Part NumberWR-160PB-VF50-N1
CategoryRectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
ManufacturerJAE Electronics
DescriptionCONN PLUG 0.5MM 160POS SMD
Package-
SeriesWR
FeaturesBoard Guide
Mounting TypeSurface Mount
Contact FinishGold
Number of Positions160
Pitch0.020" (0.50mm)
Height Above Board0.157" (4.00mm)
Connector TypePlug, Outer Shroud Contacts
Contact Finish Thickness3.9µin (0.10µm)
Number of Rows2
Mated Stacking Heights5mm, 5.5mm, 8mm

Application of WR-160PB-VF50-N1

Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) are widely used in electronic devices and systems requiring high-density and high-speed connections. In communication equipment, they are used in core equipment such as high-speed backplanes, switches and routers; In computing, such connectors are a key component in building high-performance computing platforms that support multi-processor parallel computing and high-speed memory access. In addition, in the fields of industrial automation, medical equipment, aerospace and automotive electronics, rectangular link-arrays, edge types, and sandwich types are also favored for their excellent electrical performance and reliability, and are used to achieve precise connection and control of complex circuit systems.

WR-160PB-VF50-N1 Datasheet

WR-160PB-VF50-N1 Datasheet , WR,Board Guide,Surface Mount,Gold,160,0.020" (0.50mm),0.157" (4.00mm),Plug, Outer Shroud Contacts,3.9µin (0.10µm),2,5mm, 5.5mm, 8mm

WR-160PB-VF50-N1 Classification

Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)

Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) are three different forms of rectangular connectors. Array type rectangular connectors usually refer to their internal contact pairs (that is, pins and terminals) arranged in array form, which is conducive to high-density connection, suitable for occasions where a large number of signals or data need to be transmitted. A marginal rectangular connector is a part of the edge of the circuit board that is connected, usually through pins or slots, to a gold finger or pad on the edge of the circuit board. The sandwich type (board-to-board) rectangular connector is specially designed to connect between two or more circuit boards. It directly connects the power supply and signal between the printed circuit board through the pin of the connector to achieve an efficient and stable electrical connection.

FAQ about Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)

1. What is a rectangular connector?

A rectangular connector is a connector with a basically rectangular shape and a basically rectangular mating surface. It is also an important category in the connector family. There are many varieties and specifications, and it is also widely used. It should be pointed out that the classification of rectangular connectors and printed circuit board connectors, strip connectors, and ribbon cable connectors is sometimes not strictly defined. For the same type of connector, some manufacturers classify it as a rectangular connector (approximately rectangular in shape), some as a printed circuit board connector (used in printed circuits), some as a strip connector (approximately long in shape), and some as a ribbon cable connector (connected with a ribbon cable). It is widely used in indoor cable connections, internal connections of equipment, and occasions where multiple rows of assembly are required.
2. Types of rectangular connectors?

1. In the past, it was mainly produced by enterprises under the Ministry of Electronics Industry, such as CA, CB, and CD rectangular connectors.
2. Now it is more commonly used, mainly produced by enterprises under the Ministry of Electronics.
3. J-type rectangular connectors, mainly produced by enterprises under the Ministry of Aviation and Aerospace.
4. Rectangular connectors produced according to the national military standard (GJB).
5. Rectangular connectors produced according to the International Electrotechnical Commission (IEC) standard.
3. What are the types of rectangular connectors?

1. Pin-type rectangular connector: This is the most common type of rectangular connector. The metal pin is inserted into the interface hole and rotated to tighten to achieve conductive connection.
2. Snap-on rectangular connector: It is fixed with self-locking mechanisms such as spring sheets or clips, and is suitable for use in vibration environments.
3. SMD rectangular connector (SMT type): It is suitable for use in surface mount technology (SMT), which is convenient and fast.
‌4. Board-to-board rectangular connector‌: Mainly used for interconnection of board-level and system-level circuits, with the characteristics of high-density connection, low plug-in and pull-out times, and easy maintenance.
‌5. Wire-to-board rectangular connector‌: Suitable for the connection of internal signals and power of equipment, can withstand high current and high temperature environments, and has the advantages of easy installation and convenient maintenance.
