The picture is for reference only, please refer to the product specification
- ZXTN2020FTA
- Diodes Incorporated
- TRANS NPN 100V 4A SOT23-3
- Transistors - Bipolar (BJT) - Single
- ZXTN2020FTA Datasheet
- TO-236-3, SC-59, SOT-23-3
- Cut Tape (CT)
-
Lead free / RoHS Compliant - 3530
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
What is ZXTN2020FTA
Diodes Incorporated Part Number ZXTN2020FTA（Transistors - Bipolar (BJT) - Single）, developed and manufactured by Diodes Incorporated, distributed globally by Jinftry. We distribute various electronic components from world-renowned brands and provide one-stop services, making us a trusted global electronic component distributor.
ZXTN2020FTA is one of the part numbers distributed by Jinftry, and you can learn about its specifications/configurations, package/case, Datasheet, and other information here. Electronic components are affected by supply and demand, and prices fluctuate frequently. If you have a demand, please do not hesitate to send us an RFQ or email us immediately [email protected] Please inquire about the real-time unit price, Data Code, Lead time, payment terms, and any other information you would like to know. We will do our best to provide you with a quotation and reply as soon as possible.
ZXTN2020FTA Specifications
- Part NumberZXTN2020FTA
- CategoryTransistors - Bipolar (BJT) - Single
- ManufacturerDiodes Incorporated
- DescriptionTRANS NPN 100V 4A SOT23-3
- PackageCut Tape (CT)
- Series-
- Operating Temperature-55°C ~ 150°C (TJ)
- Mounting TypeSurface Mount
- Package / CaseTO-236-3, SC-59, SOT-23-3
- Supplier Device PackageSOT-23-3
- Power - Max1.2 W
- Transistor TypeNPN
- Current - Collector (Ic) (Max)4 A
- Voltage - Collector Emitter Breakdown (Max)100 V
- Vce Saturation (Max) @ Ib, Ic150mV @ 400mA, 4A
- Current - Collector Cutoff (Max)20nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce100 @ 1A, 2V
- Frequency - Transition130MHz
Application of ZXTN2020FTA
ZXTN2020FTA Datasheet
ZXTN2020FTA Datasheet , Cut Tape (CT),-55°C ~ 150°C (TJ),Surface Mount,TO-236-3, SC-59, SOT-23-3,SOT-23-3,1.2 W,NPN,4 A,100 V,150mV @ 400mA, 4A,20nA (ICBO),100 @ 1A, 2V,130MHz
ZXTN2020FTA Classification
Transistors - Bipolar (BJT) - Single
FAQ about Transistors - Bipolar (BJT) - Single
-
1. Is BJT bipolar or unipolar?
BJT (bipolar junction transistor) is bipolar. BJT (bipolar junction transistor) is composed of two N-type semiconductors sandwiched between a P-type semiconductor, with an emitter junction formed between the emitter and the base, and a collector junction formed between the collector and the base. When the power is turned on, the majority carriers (electrons) in the emitter and the majority carriers (holes) in the base diffuse with each other, forming a current amplification effect.
The working principle of BJT is to achieve current amplification through the control of two PN junctions (emitter junction and collector junction). When the emitter junction is forward biased, electrons are injected from the emitter region into the base region; when the collector junction is reverse biased, electrons are injected from the base region into the collector region. Because the base region is very thin and the impurity content is strictly controlled, most electrons can enter the collector region through the collector junction to form the collector current Ic, and only a small number of electrons recombine with holes in the base region to form the base current Ib. Therefore, by controlling the base current Ib, the collector current Ic can be amplified to achieve current amplification. -
2. Is PNP transistor bipolar?
PNP transistor is a bipolar transistor. PNP transistor is a bipolar transistor used in electronic circuits to amplify, switch and control current. Its name "PNP" represents the three different semiconductor regions in its structure: two positive poles (P type) and one negative pole (N type).
-
3. What are the two types of BJT transistors?
There are two main types of BJT transistors: NPN and PNP.
NPN transistor
In an NPN transistor, current flows from the collector to the emitter. The base of an NPN transistor must be connected to a positive voltage for current to flow in. As the current flowing to the base increases, the transistor gradually turns on until the current is completely conducted from the collector to the emitter.
PNP Transistor
In a PNP transistor, the current flows from the emitter to the collector. Therefore, the base of the PNP transistor must be grounded. When the output current is small and the base is negative relative to the emitter, the transistor will turn on and a larger current will flow from the emitter to the collector. Basically, if the base and collector are negative relative to the emitter, the PNP transistor will conduct current from the emitter to the collector.
